30G Shock Control Stainless Steel Wire Rope Vibration Isolator for Industrial Machinery
GH all metal wire rope vibration isolator is both at home and abroad in recent years developed a new type of vibration isolator, a three-dimensional variable stiffness and damping characteristics. Can satisfy the plane, spread, tanks and oil field logging truck, ocean transportation equipment instrumentation requirement of vibration isolation and noise. Which is the electronic equipment can work normally in the bad mechanical environment and is an ideal product to replace traditional vibration isolator.
100 :-- 100N
200 :-- 200N
250 :-- 250N
300 :-- 300N
400 :-- 400N
500 :-- 500N
600 :-- 600N
Empty: The default of the carbon steel material
C1A:The surface of galvanized white
C2B:The surface of galvanized blue and white
C2C:The surface of galvanized color
C2D:The surface of galvanized army green
C2E:The surface of galvanized gold
A:304 stainless steel surface passivation
B:316 stainless steel surface passivation
L:Grey anodized 6061 - T6 aluminum alloy
P:6061 - T6 aluminum alloy surface hard
CXX:Customers customized procurement
- No creep or ageing.
- High internal damping.
- Very wide temperature range.
- Wide variety of possible fittings.
- Rapid and economical prototyping.
- Extremely rugged construction and long lifespan.
- Excellent combined shock and vibration isolation.
- Not affected by chemical agents, seawater, ozone, UV rays,...
| Applications | Typical Equipment | Protection From | Operational Advantages |
| Shipboard | Electronics, Computers, Machinery |
Explosive blast, Inherent vibration, Storms |
Long life, Maintenance-free, Temperature extremes, Corrosion resistance, All axes protection |
| Rough Terrain Vehicles | Instrumentation, Generators, Electronics |
Rough terrain, Poor road conditions, Collision |
Long life, Maintenance-free, Temperature extremes, Ozone, Radioactivity, UV Radiation |
| Aircraft | Electronics, Computers | High-G maneuvering, Hard landings, Turbulent air |
Temperature and altitude extremes, Lightweight |
| Shipping Containers | Optics, Instruments, Missiles, Electronics |
Transit, Handling drop, Loading/Unloading |
Long life, Maintenance-free, Exposure to moisture, Repeated use |
| Industrial Equipment |
Centrifuge, Dryers, Pumps |
Unbalanced dynamic loads, Fluid hammer, Inherent vibration, Foundation weakness |
Long life, Maintenance-free, Corrosive environments |
| Ordnance Equipment |
Missile launchers, Tank artillery, Computer controls, Electronics |
Rough terrain, Railroad humping, Transit | Maintenance-free, Temperature extremes, Nearby blast |
| Medical Equipment |
Mechanical equipment necessary for patient care |
Vibration from moving parts, Mobile carts-Transport shock | Maintenance-free, No out gassing, Can be sterilized |
| Chimneys |
Chimneys, Scrubbers, Measuring devices |
Wind causing resonant frequencies, Stack gas causing turbulence near scrubber, etc. |
Maintenance-free, Temperature extremes, Corrosive environments |
