China Friction Woven Brake Lining Material / Light Truck Brake Lining Roll Parts for sale

Friction Woven Brake Lining Material / Light Truck Brake Lining Roll Parts

Price Negotiable
Price: Negotiable
MOQ: 400 Kgs
Delivery Time: 18 work days
Brand: KBN
Product Description

Brown Color Friction Roll Woven Brake Lining Material Woven Roll with Brass Wire


Product Raw Materials:

Brass wire, resin, glass fiber, viscose fiber, resin and other friction materials, etc.

Its coefficient of friction has a high capacity to absorb loads by impact and excellent resistance to mechanical stress. We have more than 10 years experience in manufacturing Woven Brake Linings, which can bring mutual benefit and profits to you and us.


Application Fields:



Woven Brake Linings are widely used in decelerating and braking of engineer machines, industry machine and mining machines, such as Winch, Windlass, Tractor, Sugar Mill, Crane,Blender, Power Generator, Construction Machinery, Elevator, Lift, Pickup, Light Truck, etc.



Technical Performance:





Interface Temperature





Friction coefficient



Wear rate(CM3/NM)



100°C



0.40—0.65



≤0.7×10-7



150°C



0.35—0.65



≤1.1×10-7



200°C



0.30—0.60



≤1.3×10-7



This product is made of friction material with brass wire, resin glass fiber, and viscose fiber, is applicable to industrial machinery that requires a high degree of friction, can be used in oil wells, dredges, sugar mills, winch, cranes, construction machinery, power generators, voltage controllers, cutters of paper, stamping machines, glass melting machinery, among many other applications.



Features of Woven Brake Lining:



1. Good flexibility,

2. Excellent oil resistance and water resistance,

3. High tenacity, shock resisting, heat resisting,

4. Good duality and anastomosis, agile brake.
