Description

This Paper Making Machine And Paper Machinery In PINGAN COMPANY is specially designed to produce high grade fluting paper and kraft paper. The wire section is composed of :

1- 2sets air cushion headbox

2- forming table

3- white water pan

4- forming plate

5- dewatering plate

6- wet suction box

7- high and low suction box

8- breast roll, breast roll

9- support and lifting device

10- vacuum couch roll

11- wire driving roll

12- wire leading roll

13- doctor

14- shower

15- trim cutter, trim squirt

16- tensioner, corrector.

The fourdrinier is polyester forming wire and cantilever type wire-changing device. The jack on the operation side. Wire design tension: 7KN/m. Elongation is 1.5%.

Forming section rolls in this paper making machine

1ply wire paper making machine headbox material description
