Single Mode Fiber Optic Patch Cable 9/125 Duplex LC/UPC-LC/UPC High Dense Connection
High quality Single Mode 9/125 Duplex LC/UPC-LC/UPC Fiber Optic Patch Cord
LC fiber optic cable is available in both single-mode and multimode versions.
Both single-mode and multimode versions LC fiber patch come with a zirconia ceramic ferrule with pre-polished PC profile and convex spherical end.
These end-face types allow for faster polishing, and low back reflection and optical loss, while ensuring maximum repeatability.
Features:
- Standard exact plastic material
- Small, light, high dense connection
- Push-pull RJ-45 lockable structure, easy for operation
- Good in repeatability
- Good in exchange
Application:
- Telecommunications
- CATV, LAN,MAN, WAN, Test &Measurement
- Military industry
- Medical
Parameter:
| Parameter | Unit | Standard & Requirement | |||
| PC(SM) | UPC(SM) | APC(SM) | PC(MM) | ||
| Insertion Loss (Typical) | dB | ≤0.3 | ≤0.3 | ≤0.2 | ≤0.3 |
| Return Loss | dB | ≥45 | ≥55 | ≥60 | ≥35 |
| Mechanical Endurance (500T) | dB | ≤0.2 | |||
| Exchangeability | dB | ≤0.2 | |||
| Durability | Time | ＞1000 | |||
| Vibration | dB | ≤0.2 | |||
| Operating Temperature | ℃ | ﹣40 ～﹢75 | |||
| Storage Temperature | ℃ | ﹣45 ～﹢85 | |||
| Cable Diameter | mm | Ф3.0, Ф2.0, Ф0.9 | |||
| WHY CHOOSE US? |
| What’s your best price? |
|
Based on the quality of our products and the quantity of your order. We would quote the best matching price all the time. |
| Can you provide OEM/ODM service? |
| Yes, we can. Please let us know your detail requirements |
| Can you list some of your main customers? |
| Domestic: China Telecom, China Mobile, China Unicom, Huawei, Fiberhome, ZTE, etc. Abroad: Furukawa, Fujikura, TOT, Etisalat, STC, Commscope, Verizon, Duratel, Smart, etc. |
| Why choose YHT to cooperate? |
|
1. Reliable & Experienced communication equipment manufacturer for 16 years. three year maintenance. 7.wide products series like FTTH box,ODF,splice closure,pigtail,patch cord and others fiber optic producsts for choosing |
