12 Trays Aerial Hanger 288fibers Joint Splice Closure IP68
Price:
Negotiable
MOQ:
50pcs
Delivery Time:
10days
Brand:
CSYHT
Product Description
7 Cable Entries Aerial Hanger Waterproof 288 Fibers Joint Splice Closure
Model Number: CV016
Description:
CV016 is widely applied to the splicing, distributing variable optical cables. It is big capacity, max. 288 fibers.
Features:
1) Splice tray: Max. 12pcs, each 24cores
2) Cable port: 6pcs round port φ19.9mm, 1pc oval port 38x70mm for supporting cable entry without cutting. All cable ports are heat shrink sealing.
3) Waterproof: IP68
4) Wall-mounting, Aerial hanger and pole holding
5) Material: high impact resistance PP materials with UV
Specification:
| Model | Splice tray | Fiber core | Dimension(mm) | Net weight(Kg) |
| CV016 | 12 trays, each 24 fibers | 288 fibers | Φ228 × 527.5 | 3.31 |
