Multi Mode OM3 0.3dB G657 Fiber Optic Pigtail 0.9mm
LC APC fiber optic pigtail 0.9mm SM G652D , G657A 1.5M PVC yellow color
Fiber optic pigtail is oftern used in ODF, FTTH box, splitter box for fiber splicing and connection.
LC APC fiber optic pigtail is an optical fiber calbe that has LC optical connector pre-installed in one side and a length of fiber at the other side. LC connector can be UPC or ABS polishing. It is simplex, PVC or LSZH jacket. White, yellow or orange color.
Specification:
| Parameter | Unit |
Standard & Requirement (APC polishing) |
| Insertion Loss (Typical) | dB | ≤0.3 |
| Return Loss | dB | ≥60 |
| Exchangeability | dB | ≤0.2 |
| Durability | Time | ＞1000 |
| Vibration | dB | ≤0.2 |
| Operating Temperature | ℃ | ﹣40 ～﹢75 |
| Storage Temperature | ℃ | ﹣45 ～﹢85 |
Features:
Low insertion loss
High return loss
Excellent mechanical endurance
Good in repeatability and exchangeability
Application:
Telecommunications
FTTX
CATV
Optical communication system
Pictures:
