IP32 FTTX 2 SC Fiber Optic Faceplate Optical Rosette FTTH Wall Socket
Fiber optic faceplate 2 SC ports optical rossette 2 fibers FTTH wall socket with 2 SC adapters
Model Number: FP-015
Product Description:
FP-015 is an indoor floor mounted or wall mounted fiber optic face plate(also called fiber optic socket, wall outlets, mini fiber splice box),
it can use in soho box too.
It can load 1pc or 2pcs SC simplex fiber optic adapter, widly used FTTX FTTH FTTB telecommunication networking systems.
Features:
(1) Support MM and SM fiber connection
(2) 2 ports for SC simplex, LC duplex adapters
(3) With hinged cover, easy to open and close
(4) The bottom part of cover can turn up, easy for fiber operation
(5) Radian appearance makes it slinky
(6) ABS plastic, light weight, reasonable design
Specification:
| Model | Dimension(mm) | Material | Adapter port | Splicing capacity | Application |
| FP-000 | 86.5x86.5x20.4 | ABS | 2 SC Simplex | 2 cores | Indoor wall mounted |
| FP-008 | 86X86X25 | ABS or PP | 2 SC Simplex | 2 cores | Indoor wall mounted |
| FP-009 | 97.9x86.3x22 | ABS | 2 SC Simplex | 2 cores | Indoor wall mounted with hanged cover |
| FP-010 | 97.9x86.1x27.9 | ABS | 2 SC Simplex | 2 cores | Indoor wall mounted with hanged cover |
| FP-011 | 85x85x26 | ABS | 2 SC Simplex | 2 cores | Indoor wall mounted |
| FP-00A | 130x84x25 | ABS | 2 SC Simplex | 2 cores | Indoor wall mounted |
| FP-015 | 86.3x110.6x23 | ABS | 2 SC Simplex or LC Duplex | Max. 4 fibers | Indoor wall mouned, with hinged cover |
| FP-016 | 100x80x23.4 | ABS | 2 SC Simplex or LC Duplex | Max. 4 fibers | Indoor wall mounted |
Pictures:
