GYFFY Fiber Optic Cable Hybrid Fiber Power Cable ASU 2 FRP Self supporting

Price Negotiable

Price: 102.31+$+KM

MOQ: 10+km

Delivery Time: 10

Brand: KEXINT

Product Description

Fiber Optic Cable ASU GYFFY Hybrid Fiber Power Cable 2 FRP Self-supporting

Put 250μm colored fiber in the PBT loose tube, two FRP as strengthen member, Cable surface is extruded with PE outer sheath.


Features:

·Small Size and Light Weight
·Two FRP as strength member to provide good tensile performance

·Gel Filled or gel free , good waterproof performance

·Low price ,high fiber capacity

·applicable for short span aerial and duct installation


Technical Parameters:

Cable Core	Unit	2F	4F	6F	8F	10F	12F
No. Of Tubes		1	1	1	1	1	1
No. Of fibers	core	2	4	6	9	10	12
Fiber Counts in tube	core	2	4	6	9	10	12
Cable Diameter	mm	6.8±0.5			7.2±0.5
Cable Weight	Kg/km	40±10			45±10
Allowable tensile Strength	N	Span=80,1.5*P
Allowable crush resistance	N	1000N
Operation temperature	℃	-20℃ to +65℃


Standard:
GYFFY fiber Optic cable complies with Standard YD/T1258.4-2003,GB/T13993 ,IECA-596,GR-409,IEC794

Application:
1. As pigtail of communication equipment
2. Suitable for communication equipment servrd
3. Can be installed conveniently and perated simply
