KEXINT KXT-B-16G PLC Grey Fiber Optic Distribution Box 16 Ports Outdoor IP65 For FTTH
KEXINT FTTH KXT-B-16G 16 Ports Outdoor IP 65 PLC Grey Fiber Optic Distribution Box
KXT-B-16G fiber access termination closure is able to hold up to 16 subscribers and 96 splicing points as closure. it is used as a splicing closure and a termination point for the feeder cable to connect with drop cable in FTTX network system. It integrates fiber splicing, splitting, distribution, storage and cable connection in one solid protection box.
Features:
2. Integrated with flap-up splice cassette and adapter holder.
3. All stainless metal plate and anti-rusting bolts, nuts.
4. Fiber bend radius control more than 40 mm.
5. Suitable for the fusion splicer or mechanical splice.
6. 2 pieces of 1*8 splitter can be installed as an option.
7. Mechanical sealing structure and mid-span cable entry.
8. 16 ports cable entrance for drop cable.
9. 16 adapter for drop cable patching.
 |
Fiber optic distribution box applied to FTTH that links in the access of the terminal system, especially suitable for the outdoor wall hanging or hoop type.
| Material | Size | Max Capacity | Nos of Adaptor | Wight | Color | |
| ABS/PC |
A*B*C(MM) 287*172*102 |
Splice 16 Fibers (1trays, 16fiber/tray) |
2pc of 1*8 PLC Splitter | 16pc of SC | 1.15kg | Grey/black |
Application:
2. FTTH pre-installation and filed installation
3. 2*3 mm indoor FTTH drop cable and outdoor figure-8 FTTH self-supporting drop cable
|
|
 |
| Item | Value |
| Product No. | KXT-B-16G |
| Available Adapter | FC, SC, LC, ST |
| Size(H*W*D) | 287*172*102 mm |
| IP Level | IP 65 |
| Cable Ports | 4 into 16 out |
| Max Splice Capacity | 2 Pieces 1*8 PLC Splitter |
| Material |
ABS+PC |
Storage:
FAQ
Q1: Are you trading company or manufacturer?
A1: We are manufacturer with own factories.
Q2: Do you provide samples? Is it free or extra?
A2: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q3: What is your terms of payment?
A3: Payment≤1000 USD,100％ in advance;payment>1000USD, 30％ T/Tin advance,balance before shipment.
Q4: How long is your delivery time?
A4: Generally it is 5-10 days if the goods are in stock.Otherwise,it is 15-20 days if the goods are not in stock.It's according to the quantity of needs.
Q5: Can I negotiate the prices?
A5: Yes, we may consider diascounts for multiple container load of goods.
Q6: What is your terms of packing?
A6: Generally, we pack our goods in neutral white boxes and brown cartons.If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.
Q7: How much will the shipping charges be?
A7: It depends on the size of your shipment and the method of shipping.We will offer the charge to you as you requested.
Q8: Can you produce according to the samples?
A8: Yes, we can produce by your samples or technical drawings and build the molds and fixtures.
Q9: How about the warranty?
A9: There are 12 months for the warranty.While the warranty is not responsible for those broken by violence or uopdated with other brands.
Q10: What is your terms of delivery?
A10: EXW,FOB,CFR,CIF,DDU,DDP.
Q11: Can I visit you?
A11: Sure, one of our factories is in Shenzhen,China.Please contact us to make an appointment.
