8 Core Indoor Armored Fiber Optic Cable Computer Room 0.6 Tube SOS Indoor G657a2

    The structure of the cable is put Φ600μm tight buffer fibers with aramid yarn,then covered with a layer of PVC or LSZH inner sheath,then wrapped a layer of flat stainless steel wires and add a layer of woven stainless steel wire,finally into fiber optic cable with PVC or LSZH or OFNROR or PE sheath.

Description:

      Specifically for field wiring and complexity of environment, designed for repeated retractable conditions application, light weight, anti-tension, compression and strong; softness; easy to bend; abrasion, flame retardant, suit for widely range temperature. Communication systems for military field wiring or repeated rapid retractable; radar, aviation and ship wiring; oilfield, mine, port, broadcast live on television, communication line repair, and other harsh conditions of the occasion

Features:

      a. Wiring compact all-dielectric structure, the inner sleeve is 0.9mm fiber, the cable has a high strength-weight ratio, allowing for quick wiring;

      b. High-strength fiber composite structure secondary coating offers the best performance and minimum temperature of the additional attenuation cables in harsh conditions to ensure the reliability and service life;

      c. Large area of aramid reinforced fiber optic cable to provide a high mechanical strength;

      d. A special high-strength, flexible type central reinforcing element, to ensure fiber strength and bending properties;

      e. Small tight pitch SZ stranded helical twisted fibers and aramid fibers single combined to ensure the field fiber optic cable has greater tensile strain capacity;

      f. Environmental friendly, Comply with RoHS.

Applications:

      1.Military Communications;

      2.Coal, oil, natural gas, etc.

      3.Geological exploration Communications;

      4.Broadcast television;

      5.Emergency reopened optical fiber communication.

Technical parameter:

Packing:

    a Nominal shipping length of the cable will be 1~3 km. Other length is also available if required by buyer.

    b Each length of the cable will be wound on a separate strong wooden.

    c Both ends of the cable will be sealed with a suitable heat shrinkable cap to prevent the entry of moisture during transportation and storage.

    d The cable end will be securely fastened to the drum to prevent the cable from coming loose during transit or becoming loose during placing operations.

    e  Circumference battens will be secured between the outer edges of the flange to protect the cable against damage during shipment and storage.

    f  For testing purposes, the inner end of the cable will be recessed into a slot in the drum flange . A minimum length of one meter of cable at the inner end will be accessible.

    g The cable will be shipped on drums designed to prevent damage to the cable during shipment and installation

    h The minimum barrel diameter of the drum will be 30 times to the overall cable diameter.

Product structure design:

     8 core armored optical cable structure: 0.5mm PVC tight-packed optical fiber*8+stainless steel hose+aramid yarn+PVC sheath

     Stainless steel pipe size: outer diameter: 2.7~2.8mm wall thickness: 0.7mm inner diameter: 2.0~2.1mm gap: 0.25~0.35mm

Stainless steel pipe material: SUS204

     Optical fiber: single-mode G652D/G657A, multi-mode 62.5/125, 50/125 (10G OM3/OM4)

Diameter: 0.5~0.55mm

     Aramid: imported 1000DEN; quantity: 8 shares

    Plastic sheath: flame-retardant PVC, LSZH (low smoke and halogen-free), high abrasion-resistant flame-retardant halogen/non-flame-retardant TPU sheath (thermoplastic polyurethane) for indoor and outdoor use, high flame-retardant sheath material OFNP, outdoor Use waterproof and wear-resistant black PE Outer diameter of sheath: 4.5±0.2mm;Sheath thickness: 0.6-0.8mm;Standard colors: SM is blue; MM is gray. Color can also be customized according to customer requirements.
