0.2-1.6mm A3105 H26 Colorful Prepainted Aluminium Coil – PE/PVDF Coating for Aesthetic Construction Cladding
Price:
Negotiable
MOQ:
1000 Kgs / 1 Metric Ton
Delivery Time:
Within 35 Days After Order Confirmed And Down Paymetn Received
Brand:
Dingang
Product Description
Introduction
Specification
|
Product Name
|
Pre-painted aluminum coil
|
|
Grade
|
1000 ,2000, 3000, 5000 series
|
|
Thickness
|
0.2mm-2.5mm
|
|
Width
|
Max 1600mm
|
|
Length
|
According to weight
|
|
Painting
Thickness |
Top side: 10-25microns;
|
|
Primer: 5~7microns.
|
|
|
Back side:5~12microns.
|
|
|
Color
|
RAL color Or as customer's sample
|
|
Coil ID
|
508mm
|
|
Packing
|
waterproof paper+plastic film+iron packing+bundling,
or as per customers request. |
|
Application
|
Corrugated steel sheet,refrigeration,cold storage,door panel,sandwich panel,
writing board, shipping |
|
Delivery Time
|
15 days after received pre-payment
|
|
Min Order
|
2 Mt for common sizes
|
Product Detail Temper
|
Variety
|
Alloy
|
Temper
|
Size(mm)
|
Adopted Standard
|
|
|
Thickness
|
Width
|
||||
|
Hot rolled coil
|
1x3x5x8x series
|
OFH112
|
2.5~7.0
|
900~1700
|
GB/T16501
|
|
Stock for micron foil
|
1235
|
H14
|
0.25~0.50
|
900~1500
|
EL/X79
EL/X24 |
|
Coating sheet
|
1x3x5x series
|
H14H16H18H22H24H26
|
0.18~0.75
|
1200~1550
|
EL/X260
|
|
Curtain coil
|
11003003
|
H12H22H24H26
|
1.5~3.0
|
1000~1500
|
SWA/X2402
|
|
50055052
|
H22H24H32H34
|
||||
|
Lithographic coil
|
1050
|
H18
|
0.23~0.28
|
650~1500
|
YS/T421
EL/X251 |
|
Can stock
|
3104
|
H19
|
0.28~0.31
|
1000~1550
|
YS/T435
|
|
Ceiling stock
|
1x3x series
|
H14H24H16H26
|
0.4~1.0
|
200~1450
|
X/SWA21211
|
|
50055052
|
H24H22
|
||||
|
Bottle lids stock
|
8011
|
H16H18
|
0.20~0.30
|
500~1550
|
YS/T91
EL/X273 |
|
Coil for Al-composite pipe
|
1x3x8x series
|
OH22
|
0.2~1.5
|
30~1550
|
YS/T434
|
|
Other coils
|
1x3x8x series and 50055052
|
OH1xH2x
|
0.20~6.0
|
60~2400
|
GB/T8544
EL/X246 |
|
5x series
|
OH1xH2xH3x
|
0.3~4.0
|
900~2000
|
||
|
2x6x series
|
OH18
|
0.5~4.0
|
900~1800
|
||
|
Remark:coil inner diameter for 405505605mm could be supplied,maximum coil outer diameter is 1750mm.
|
|||||
Coating type
Paint coating: Paint coatings are applied to aluminum coil using spray painting, roll coating, or other painting methods. These coatings can be either organic or inorganic and can provide good color retention, corrosion resistance, and durability. Paint coatings can be applied in a wide range of colors and finishes to meet specific design requirements.
Powder coating: Powder coating is a type of dry coating that is applied to aluminum coil using electrostatic spraying. The powder is then fused onto the surface of the aluminum coil through heating, forming a smooth and uniform coating. Powder coatings are durable, scratch-resistant, and have good color retention.
Anodizing: Anodizing is an electrochemical process that converts the surface of aluminum into a durable oxide film. This oxide film can be dyed to achieve different colors and provides corrosion resistance, wear resistance, and scratch resistance. Anodizing is often used to create a decorative finish on aluminum coil.
PVC coating: PVC (polyvinyl chloride) coating is a type of plastic coating that is applied to aluminum coil using extrusion or lamination methods. PVC coatings are flexible, waterproof, and have good chemical resistance. They are often used in building materials, such as aluminum composite panels, to provide durability and protection against weathering.
Our sale service
1.Sample can be offered .
2.We have 30 years experience of manufacture steel material, we cherish every order from our honor.
3. We have full stock,and can deliver within short time.Many styles for your choices.
4.OEM and ODM order are accepted, Any kind of logo printing or design are available.
5.Good Quality + Factory Price + Quick Response + Reliable Service
6.All of our products are produce by our professional workman and we have our high-work-effect foreign trade team, you can totally believe our service.
