Color Coated Aluminum Sheets 1.5mm Thickness for Caravan & RV Exteriors
Price:
Negotiable
MOQ:
1000 Kgs / 1 Metric Ton
Delivery Time:
Within 35 Days After Order Confirmed And Down Paymetn Received
Brand:
Dingang
Product Description
Product Overview
Our 1.5mm thick color coated aluminum sheets are specifically engineered for caravan and RV exterior applications, combining durability, aesthetics, and functionality to elevate your vehicle’s performance and appearance. Crafted with high-grade aluminum alloy and advanced coating technology, these sheets offer exceptional resistance to harsh outdoor conditions while maintaining a lightweight profile—ideal for enhancing fuel efficiency and extending the service life of your caravan or RV.
Key Features & Benefits
Optimal Thickness for Exterior Use: The 1.5mm gauge strikes the perfect balance between structural rigidity and weight savings. It provides sufficient strength to withstand road vibrations, wind pressure, and minor impacts, without adding unnecessary bulk to your vehicle.
Superior Corrosion Resistance: The multi-layer coating system (primer + topcoat) forms a protective barrier against rain, snow, UV radiation, salt spray, and humidity—common threats to RV exteriors. This ensures long-term resistance to rust, fading, and peeling, even in extreme climates.
Lightweight & Fuel-Efficient: Aluminum’s natural lightness (only 2.7g/cm³ density) reduces the overall weight of your caravan/RV, improving towing efficiency and reducing fuel consumption. Compared to steel alternatives, it eases handling and minimizes wear on chassis components.
Vibrant, Long-Lasting Color Options: Choose from a wide range of standard and custom colors (including matte, glossy, and metallic finishes) that retain their brilliance for years. The coating is scratch-resistant and easy to clean, keeping your vehicle looking sleek and well-maintained.
Weatherproof & Temperature Resilient: Designed to perform in temperatures ranging from -40°C to 80°C (-40°F to 176°F), these sheets resist thermal expansion and contraction, preventing warping or cracking under extreme heat or cold.
Easy Installation & Versatility: The sheets are precision-cut to custom sizes (per your requirements) and feature a flat, uniform surface for seamless bonding, riveting, or screwing. Suitable for sidewalls, roofs, fenders, and other exterior panels.
Technical Specifications
|
Parameter
|
Details
|
|
Material
|
3003/5052 Aluminum Alloy (food-grade, non-toxic)
|
|
Thickness
|
1.5mm (tolerance: ±0.05mm)
|
|
Coating Type
|
Polyester (PE) / PVDF (Kynar 500) coating
|
|
Coating Thickness
|
Primer: 5-8μm; Topcoat: 15-25μm
|
|
Sheet Size
|
Customizable (max width: 1600mm; length: up to 6000mm)
|
|
Surface Finish
|
Matte / Glossy / Metallic
|
|
Hardness
|
≥2H (pencil test)
|
|
Adhesion
|
Grade 0 (cross-cut test, no peeling)
|
|
Weather Resistance
|
≥1000 hours UV aging test (no fading/peeling)
|
|
Corrosion Resistance
|
≥500 hours salt spray test (no rust)
|
|
Fire Rating
|
Class A (non-combustible)
|
Why Choose Our Color Coated Aluminum Sheets?
RV-Specific Design: Tailored to meet the unique demands of caravan/RV exteriors—lightweight, durable, and weatherproof.
Premium Quality Assurance: Manufactured under ISO 9001 and ASTM standards, with strict quality control from raw material to finished product.
Cost-Effective: Long service life (15-20 years) reduces maintenance and replacement costs compared to traditional materials.
Eco-Friendly: 100% recyclable aluminum, low-VOC coating, and energy-efficient production process.
Customization Support: We offer custom sizes, colors, and coating options to match your specific design needs.
Application
Caravan/RV sidewalls, roofs, and fenders
Camper van exterior panels
Travel trailer decorative and protective sheets
Motorhome exterior renovations and upgrades
Packaging & Shipping
Each sheet is wrapped in PE film and protected by foam boards to prevent scratches during transportation.
Packed in wooden pallets or cartons (custom packaging available).
Global shipping with reliable logistics partners (DHL, FedEx, sea freight) for timely delivery.
Contact Us
For inquiries about pricing, samples, or custom orders, please feel free to contact our sales team. We provide professional technical support and after-sales service to ensure your satisfaction.
