1.3mm Color Coated Aluminum Sheet 1220×2440mm – Premium Cladding for Facades & Partitions
Price:
Negotiable
MOQ:
1000 Kgs / 1 Metric Ton
Delivery Time:
Within 35 Days After Order Confirmed And Down Paymetn Received
Brand:
Dingang
Product Description
Product Description
Introducing our 1.3mm Color Coated Aluminum Sheet in the standard 1220×2440mm size – a tailor-made premium cladding solution designed exclusively for building facades and interior partitions. Combining exceptional structural stability, long-lasting aesthetics, and easy installation, this aluminum sheet is the top choice for architects, contractors, and project developers aiming to elevate both commercial and residential spaces.
Crafted with high-quality aluminum alloy, the 1.3mm thickness strikes the perfect balance between lightweight flexibility and reliable rigidity. It easily adapts to various fabrication needs, such as cutting, bending, and shaping, without compromising structural integrity – ideal for creating sleek, modern facade designs or functional, partition layouts. The standardized 1220×2440mm dimension ensures seamless material utilization, minimizing waste and reducing installation time, making it a cost-effective option for large-scale and small-scale projects alike.
Our advanced color coating technology sets this sheet apart. Available with PVDF, FEVE, or PE coatings, it delivers superior weather resistance (UV protection, rainproof, and temperature fluctuation resistance) for exterior facade applications, ensuring long-lasting color retention and no peeling or fading for up to 20 years. For interior partitions, the coating offers excellent scratch resistance and easy maintenance, keeping the surface looking pristine even in high-traffic areas. Choose from a full spectrum of RAL and Pantone colors, as well as matte, glossy, or satin finishes, to match any architectural style or design vision.
Product Parameters of Color Coated Aluminum Sheets
|
Parameter
|
Details
|
|---|---|
|
Alloy Grade
|
AA3003 / AA5052 (optional, non-heat-treatable Al-Mn/Al-Mg alloy)
|
|
Thickness
|
1.3mm (precision tolerance: ±0.05mm)
|
|
Dimensions
|
1220×2440mm (standard size; custom cuts available on request)
|
|
Coating Type
|
PVDF (2-coat/3-coat), FEVE, PE; Back coating: 5–10μm protective layer
|
|
Coating Thickness
|
PVDF: 25–35μm; PE: 15–25μm
|
|
Color & Finish
|
Full RAL & Pantone color range; matte, glossy, satin, metallic finishes
|
|
Mechanical Properties
|
Tensile strength: 110–150MPa; Elongation: ≥15% (after annealing)
|
|
Corrosion Resistance
|
Salt spray test: ≥2000 hours (no blistering/peeling); UV resistance: ≥3000 hours
|
|
Standards Compliance
|
ASTM B209, EN 485, GB/T 3880, AAMA 2605 (for PVDF coating)
|
|
Core Applications
|
Building facades, exterior cladding, interior partitions, decorative wall panels
|
Key Advantages for Facades & Partitions
Optimal Thickness for Cladding: 1.3mm provides sufficient rigidity to withstand wind loads for facades, while remaining lightweight to reduce building structural stress.
Standard Size for Efficiency: 1220×2440mm is a universal dimension that fits most cladding and partition frameworks, enabling quick installation and minimizing material waste.
Durable Coating for All Environments: Weather-resistant coatings suit outdoor facades in coastal, industrial, or urban areas; scratch-resistant surface is ideal for high-traffic interior partitions.
Aesthetic Versatility: Customizable colors and finishes allow seamless integration with modern, minimalist, or luxurious architectural styles.
Eco-Friendly & Sustainable: 100% recyclable aluminum aligns with green building standards (LEED compliant), making it a responsible choice for eco-conscious projects.
Whether you’re designing a striking commercial facade that stands out in the city skyline or creating functional, stylish interior partitions for offices, hotels, or residential buildings, our 1.3mm Color Coated Aluminum Sheet 1220×2440mm delivers unmatched performance, aesthetics, and value. Backed by strict quality control and professional technical support, we ensure consistent product quality and reliable supply to meet your project deadlines.
