PE PVDF 0.2 To 1.6mm Pre Painted Aluminium A3105 H26 1100 3003 5050 Series

PE PVDF prepainted aluminum 0.2-1.6mm A3105/H26 (1100, 3003, 5050 series)

1) The type of paint: PVDF(mainly), PE mainly
2) Thickness coating: PVDF: More then 25 micron; PE, more then 18 micron.
3) Paint: PPG
4) Interior diameter: 405mm, 505, mm
5) Width: Less then 1600mm, sheets are also available
6) Color: Panton, RAL or refer to customers' counter sample.
7) Coating hardness: (pencil hardness) more than 2H
8) Impact resistance: No cracking and peeling(50kg/cm, ASTMD-2794: 1993)
9) Flexibility(T-bend): No more than 2T
10) MEK resistance: More than 100

The base of Pre painted aluminum coil details:
1) Temper of Pre painted aluminium coil: H14, H18, H24 mainly.

2) Alloy of Pre painted aluminium coil: 1100, 1050, 3003, 5052, 8011 etc

3) Origin: China

4) Minimum order quantity of Pre painted aluminium coil: 5 tons each size

5) Lead Time of Pre painted aluminium coil: Within 20 days

6) The term of payment of Pre painted aluminium coil: T/T, irrevocable L/C at sight

7) Application of Pre painted aluminium coil: Lighting, printing, packing, decorative, electronics surface, hot rolled thick plate, PS base plate, aluminum plastic base plate, aluminum curtain wall base plate, aluminum composite panel base plate, aluminum spacer, aluminum embossed sheet, aluminum tread plate

8) Remarks of Pre painted aluminium coil: Specific requirement of alloy, temper or specification can be discussed at your request.
