20Khz 5000W Ultrasonic Metal Welding Machine for No Ferrous Metal Plate

Description:

Ultrasonic metal spot welding machine is a solid phase welding method. The connection between the weldments is completed by the high frequency elastic oscillation of the acoustic system and the static clamping between the workpieces. In the meantime, the ultrasonic generator is a frequency conversion device, which changes the common frequency current to the vibration current of the ultrasonic frequency, and the transducer converts the ultrasonic frequency electric energy fed by the generator into mechanical oscillation energy according to the "piezoelectric effect". The concentrator is used to amplify the amplitude and is used to couple the load. The weldment transforms the elastic oscillation energy into the collision energy, the deformation energy and the thermal energy between the workpieces under the action of the static pressure and the elastic oscillation energy, so that the two workpieces form a surface. The outer layer of the oxide film then reaches the conflict soldering. When different metal materials are welded, they will form a mixed molecular interface and produce metallurgical welding.

Specifications:

Features:

1. Ultrasonic metal welding equipment control mode is divided into time mode and energy mode, height mode, three welding modes

2. The equipment uses international high-quality components to ensure stable operation and short welding time.

3. After welding, the conductivity is good, the resistivity is extremely low or close to zero, the welding metal surface is required to be low, and the oxidation or electroplating can be welded.

4. Strong welding force, good electrical conductivity, and no pollution, saving manufacturing and maintenance costs.

5. Unique structural design, easy installation, maintenance and operation, convenient welding head replacement, reducing downtime and production cost
