20Khz Ultrasonic Spot Metal Welder for Voltage Electrical Components Application

Description:

Ultrasonic metal welding machine uses high-frequency vibration wave to transmit to two metal surfaces to be welded. Under pressure, the two metal surfaces rub against each other to form a fusion between molecular layers. The advantage is that it is fast. , energy saving, high fusion strength, good electrical conductivity, no spark, close to cold processing; the disadvantage is that the welded metal parts can not be too thick (generally less than or equal to 5mm), the solder joints can not be too large, need to be pressurized.

Principle of Ultrasonic metal welding:

In the case of pressurization, high-frequency vibration waves are transmitted to the two metal surfaces to be welded by ultrasonic metal welding. The two metal surfaces are rubbed together to form a fusion between the molecular layers, which has the advantages of rapidity, energy saving, high fusion strength, good electrical conductivity, no spark, and near cold processing; the disadvantage is that the welded metal parts cannot be too thick, generally Less than or equal to 5mm, the solder joints should not be too large and require pressurization.

Specifications:

Application:

1) Nickel-metal hydride battery Nickel-metal hydride battery nickel mesh and nickel sheet inter-melting and nickel sheet inter-melting. .
2) Lithium battery, polymer battery copper foil and nickel sheet are mutually melted, and aluminum foil and aluminum sheet are mutually melted. .
3), the wires are mutually melted, and they are entangled into one and a plurality of mutually melted.
4), the wire and the name of the electronic components, contacts, connectors and mutual fusion.
5), the mutual melting of large-scale heat sinks, heat exchange fins, and honeycomb hearts of famous household appliances and automotive products.
6), electromagnetic switch, no fuse switch and other large current contacts, mutual melting of dissimilar metal pieces.
7) The sealing and cutting of the metal pipe can be water and airtight.
The ultrasonic metal welding machine transmits high-frequency vibration waves of tens of thousands of times per second to the surface of two metal workpieces to be welded, and then applies a certain pressure to make the metal surfaces rub against each other to form a fusion between the molecular layers. , to achieve the purpose of welding.

20Khz Ultrasonic Spot Metal Welder for Voltage Electrical Components Application
