High Speed Strip Food Ultrasonic Cutting Machine With 2kgs Cutting Blade

Price Negotiable
Price: Negotation
MOQ: 1 unit
Delivery Time: 3 workdays
Brand: QRsonic
Product Description


High Frequency 40Khz Ultrasonic Slicing for Ultrasonic Strip Food Cutters with 2kgs Cutting Blade


Description:

QRsonic ultrasonic food cutting knives are often used to cut the most common desserts and candies, whether it is soft or contain fat, sugar, honey, cream or chocolate, which does not affect the uniformity of the food in any way.
Compared to traditional cutting methods, QRsonic ultrasonic food cutting knives are characterized by more hygienic cutting, easier equipment cleaning, shorter downtime, better cost-effectiveness, higher consistency of cutting surfaces and longer blade life.
The width of blade can be customized according to customer's requirements.


Specifications:


Item NoQR-FC40Y
Power800W
GeneratorDigital generator
Frequency40KHZ
Voltage220V or 110V
Cutter Dimension72*82.5*25.5mm
Weight of blade1.5kgs
Gross weight13Kgs



Technical Parameters:


Item NoQR-FC40YQR-FC255YQR-FC305YQR-FC355Y
Frequency40khz20khz20khz20khz
Power800w2000w2000w2000w
Generatordigital generatordigital generatordigital generatordigital generator
Voltage110V or 220V110V or 220V110V or 220V110V or 220V
Width of Blade82.5mm255mm305mm355mm
Material of bladeTitanium AlloyTitanium AlloyTitanium AlloyTitanium Alloy
Gross weight10kgs15kgs16kgs18kgs



Advantages and characteristics:

1. High stability: The ultrasonic generator generates electromagnetic vibration when it is working, and converts it into mechanical oscillation and transmits it to the cutting knives and cutting materials. The mechanical cutting is performed, so no sharp cutting edge is needed, and the blade wear is small, and at the same time The cutter head can be replaced by itself.
2. Safety and environmental protection: When the ultrasonic knife is cut, the temperature of the cutter head is lower than 50 degrees Celsius, and no smoke and odor will be generated, which eliminates the danger of injury and fire during cutting.
3. Cutting neatly: Since the ultrasonic wave is cut by high-frequency vibration, the material will not adhere to the surface of the blade, only a small pressure is required for cutting, and the fragile and soft materials are not deformed and worn, and the fabric is cut and automatically sealed. Will not cause chipping.
4. Simple operation: the cutting knife is connected to the ultrasonic generator, the generator is connected to 220V mains, and the switch can be cut to support hand-held and machine-mounted cutting.





High Frequency 40Khz Ultrasonic Slicing for Ultrasonic Strip Food Cutters with 2kgs Cutting Blade
