High Power 3600w Ultrasonic Welding Transducer 15Khz with 70mm Diameters Ceramics

Description:

Ultrasonic Oscillator, as the name suggests, are functional components that match the amplitude of ultrasonic vibrations with ultrasonic transducers. Its main function is to change the amplitude of the transducer (generally increase), improve the vibration ratio, improve the efficiency, improve the mechanical quality factor, enhance the heat resistance, expand the temperature range, and extend the service life of the transducer. The ultrasonic transducer adjusts the load matching between the transducer and the ultrasonic tool head by installing a horn (ultrasonic horn), which reduces the resonance impedance and makes it work at the resonant frequency to improve the electro-acoustic conversion efficiency. Reduces the heat generation of the ultrasonic transducer and increases the service life.

Specifications:

Parameters:

In the following cases, the admittance circle and conductance curve of the piezoceramic or transducer may be abnormal:

1) The transducer cracks during assembly.

2) Piezoelectric ceramics have problems themselves, such as internal delamination.

3) There is a problem with the design or assembly of the ultrasonic horn and the mold.

4) The parts around the stress rod caused by the difference in concentricity of the transducer collide. Generally, the admittance graph and parameters are related to each other. If the admittance graph of the vibrator is normal, R1 is lower and Qm is higher. Otherwise, if the admittance graph of the vibrator is abnormal, R1 is generally larger and Qm is smaller. .
