Low Visibility Anti Tank Wire Mesh MZP Putanka 10x10m Steel Barrier
Meet the Mzp Putanka—an unassuming guardian that melts into the landscape while it locks it down. This low-visibility steel mesh net threads razor-edged filaments through a matte, non-reflective lattice so fine it disappears at fifty meters, yet strong enough to tangle tank tracks and snag low-flying drones without a ripple on radar. Weighing less than a rucksack and unfurling in minutes, the Putanka turns hedgerows, rubble and ridge lines into silent kill zones, delivering battlefield denial with zero footprint and zero warning.
The MZP barrier prevents approach to protected objects. Individuals become entangled in the rings and typically cannot escape without assistance. The barrier also effectively stops wheeled and tracked vehicles by winding around wheels or tracks.
| Attribute | Value |
|---|---|
| Material | 0.5mm, 0.6mm, 0.8mm, 0.9mm Steel Wire, Strong |
| Wire Thickness | 0.5 - 0.8 mm |
| Brand Name | HEBEI KN |
| Delivery Time | 7 days per 40ft Container |
| Surface Treatment | Oil Protection, Water proof paper, Shrink Film |
| Product Name | Low Visible Wire, Invisible Wire Mesh, MZP, MPP |
| SIZE | 10x10x1.1-1.4 or 10x5x1.1-1.4m |
| Type | More Grands |
| MOQ | 100 SET |
| Key Words | low-visibility wire mesh, MZP, MPP |
| Sample | Available |
| Package | oil protection, shrink film |
| Weight | 26-30kgs |
| Open Size (M) | Weight (KG) |
|---|---|
| 10 x 10 x 1.1-1.4 | 30 -30.5 kg |
| 10 x 10 x 1.1-1.4 | 26.5 - 27 kg |
| 10 x 5 x 1.1-1.4 | 24.5 - 25 kg |
Weight of the set: Up to 30 KG
Folded dimensions: Length 1200mm, Width 600mm, Height 120mm
Expanded dimensions: Area 10x10m, Height: 1.1 - 1.4m
Wire diameter: 0.5 - 0.9mm
Set includes: 40 steel rings, 40 steel pegs
Warranty: 3 years
- Oil Protection: First step requires spraying oil on the surface of the wire mesh
- Water Proof Paper: Second layer uses water proof paper for protection
- Shrink Film: Final layer uses shrink film to secure the package
- Rings
- Pegs (9 peg or 7 peg configurations)
Our No.1 workshop features approximately 100 production platforms, capable of producing around 500 sets per day.
When encountering the barrier, individuals become entangled and typically cannot escape without assistance. For vehicles, the wire wraps around wheels/tracks, creating a metal pile on the chassis that prevents movement and is difficult to remove.
| Parameter | Specification |
|---|---|
| Unfolded dimensions | 10x10x1.1-1.4 m |
| Wire diameter / number of garlands | 0.9 mm / 20 pieces 0.8 mm / 20 pieces 0.6 mm / 20 pieces 0.5 mm / 20 pieces twist - 0.8 mm |
| Folded dimensions | 1.2x0.6x0.8 m |
| Package weight without rings and peg | 29 kg |
| Complete set | 40 rings + 40 pegs |
Step 1: Place the coil at the desired installation location. Note: After deployment, the MZP cannot be reassembled into its original coil.
Step 2: Divide the bay into two parts and lay them out in opposite directions (no cutting required).
Step 3: Stretch two rows of the bay to their full length.
Step 4: Lay each row outwards to create four rows from the initial two.
Step 5: Fix the coil with nails, securing the thick coil first. This creates thick lines at the bottom with thin lines extending upward.
| Year Founded | 2018 |
| Export Experience to Ukraine | Yes (Egoza, Putanka products) |
| Employees | 820 |
| Daily Output (MZP/Putanka) | ~800 units |
| Monthly Export Capacity | 4-8 containers |
| Company Type | Manufacturer with export capability |
| Annual Revenue | CNY71,550,000 |
| Export Ports | Qingdao, Tianjin, Ningbo etc. |
| Key Personnel Experience | 7 years (Cora) |
