5mm MIL7 Heavy Duty Hot Dipped Galvanized Military Defensive Bastion Barriers
5mm MIL7 Heavy Duty Hot Dipped Galvanized Military Defensive Bastion Barriers
Why Governments & Clients Choose to Cooperate with Hebei KN Wire Mesh
- Cost Efficiency
Bulk Savings: Orders of 400+ units qualify for 15–30% volume discounts.
Reusability: 95% of barriers can be redeployed after pressure-washing, cutting long-term costs compared with concrete structures.
- Customization & Compliance
Threat-Based Engineering: Provide your blast or flood protection requirements, and we will deliver designs compliant with ASTM F2656.
- Global Logistics
Fast Shipping: Folded barriers occupy 80% less space.
1. Flood Defense for Communities
2. Coastal & Riverbank Erosion Control
3. Construction & Industrial Applications
| Attribute | Value |
|---|---|
| Raw Material | Hot dipped galvanized wire |
| Geotextile | 250 - 300 g/㎡ Standard |
| Mesh Diameter | 4.0 / 5.0mm Diameter |
| Aperture | 3" (76.2mm×76.2mm) |
| Color | Military Green, sand color |
| Accessories | Staple, Joint Pin |
| Brand | KESCO, not HESCO |
| Sample | Free sample available |
| Stock | Some types in stock - welcome to inquire |
| Model | Height | Width | Length |
|---|---|---|---|
| KN-1 | 54" (1.37M) | 42" (1.06M) | 32'9" (10M) |
| KN-2 | 24" (0.61M) | 24" (0.61M) | 4' (1.22M) |
| NK-3 | 39" (1.00M) | 39" (1.00M) | 32'9" (10M) |
| KN-4 | 39" (1.00M) | 60" (1.52M) | 32'9" (10M) |
| KN-5 | 24" (0.61M) | 24" (0.61M) | 10' (3.05M) |
| KN-6 | 66" (1.68M) | 24" (0.61M) | 10' (3.05M) |
| KN-7 | 87" (2.21M) | 84" (2.13M) | 91' (27.74M) |
| KN-8 | 54" (1.37M) | 48" (1.22M) | 32'9" (10M) |
| KN-9 | 39" (1.00M) | 30" (0.76M) | 30' (9.14M) |
| KN-10 | 87" (2.21M) | 60" (1.52M) | 100' (32.50M) |
| KN-11 | 48" (1.22M) | 12" (0.30M) | 4' (1.22M) |
| KN-12 | 84" (2.13M) | 42" (1.06M) | 108' (33M) |
| KN-19 | 108" (2.74M) | 42" (1.06M) | 10'5" (3.18M) |
- Flood Prevention Barrier: From simple perimeter walls to complex base infrastructure, our products provide rapid expeditionary protection
![Hesco barrier used as flood prevention barrier]()
- Permanent or Semi-permanent Dike: Effective barriers against flooding in both temporary and permanent installations
![Military defensive barriers serving as flood control dikes]()
- Flood Control Retaining Wall: When filled with sand and earth, these gabion boxes form sturdy retaining walls against floodwaters
![Gabion boxes used as flood control retaining walls]()
- Coastal Protection: Increasingly used in seaside areas as protective fencing against erosion
![Hesco barriers protecting coastal areas]()
- Existing Structure Protection: Safeguards buildings and infrastructure from environmental damage
- Coastal Erosion Control: Effective solution for stabilizing shorelines and preventing land loss
Constructed from galvanized, rust-protected alloy wire mesh with a guaranteed minimum lifespan of 5 years in exposed environments and 10 years when stored properly.
Mesh panels connected by spring joints allow 360° rotation, enabling compact storage and transportation while maintaining structural integrity.
Combination of heavy-duty mesh panels with thick geotextile fabric creates exceptionally strong protective barriers for various applications.
