Principle of carbon - loaded nitrogen purification O₂ + C ----- CO + CO₂

Using the principle of carbon monoxide and carbon dioxide generated by the catalytic reaction of oxygen and palladium carbon fiber, the residual oxygen in nitrogen reacts in a deaerator equipped with efficient palladium carbon fiber to remove oxygen impurities, and then after cooling and adsorption, the two stages of drying and dewatering, high purity nitrogen is obtained.The core component of oxygen removal is palladium carbon fiber. Palladium and other precious metals play a catalytic role in palladium carbon fiber.

Products Advantages:

● Pure gas without hydrogen, suitable for product nitrogen without hydrogen environment

● Simple principle, reasonable structure and low energy consumption

● Gas index with low dew point, low impurity content

● Optional automatic system, the whole process can realize unattended

● Wide application range, no special requirements for raw gas

Technical Parameter(Stable and adjustable pressure, purity and flow to meet different needs of customers):

Ordinary nitrogen:

● Pressure ——≤0.7Mpa
● Atmospheric dew point ——≤－40℃
● Nitrogen purity ——≥99.99%
● Processing capacity ——100Nm³/h

High Purity Nitrogen:

● Flow of Purity Nitrogen —— ≤60Nm3/hr
● Purity——99.9995%
● Pressure——≤0.5Mpa
● Atmospheric dew point ——≤－70℃

Remark:When the raw gas contains higher oxygen content and dew point, it is necessary to consider fractional oxygen and water removal.It is recommended that the content of nitrogen and oxygen should be less than 0.1%, which can greatly reduce the consumption of carbon deoxidizer and reduce the cost.
