Automatic Operation Of Oxygen Making Machine With Different Flow

Working Principle Description:

The principle of PSA is that under the condition of adsorption equilibrium, when adsorbent adsorbs the same gas, the higher gas pressure is, the greater adsorption capacity has. In the contrast, the lower the pressure is, the smaller adsorption capacity has.

The core part of PSA oxygen production equipment is zeolite molecular sieve. When the air pressure increases, zeolite molecular sieve will absorb a large amount of nitrogen, carbon dioxide and water.

When the pressure drops to normal pressure, the adsorption capacity of zeolite molecular sieve to nitrogen gas, carbon dioxide and water is very small. In order to achieve the effect of nitrogen and oxygen separation, oxygen can be obtained in accordance with the index.

Product Advantages:

· Optional flow rate can meet different requirements;

· Control system controls the purity and the flow adjusting the cycle time of the PSA system;

· Fast start-up speed, 15 ~ 30 minutes can provide qualified oxygen ;

· Dependable highest reliability with energy efficiency;

· Low maintenance and automatically running ensure that the machine can control easily.

Technical parameters:

● Oxygen delivery ≤48Nm3/hr;

● Purity 93%±3

● Pressure 0.4~1.0 Mpa

● Atmospheric dew point ≤－40℃

Product picture:
