Skid Mounted , Different Gas Flow Of PSA Oxygen Plant

Working Principle Description:

PSA oxygen production equipment is also called pressure swing adsorption oxygen production equipment, the role is to obtain high purity oxygen (93%± 3).

Its working principle is: pressure swing adsorption (PSA) is a process in which oxygen and nitrogen in the air can be separated and purified by using adsorbent (zeolite molecular sieve) with different adsorption capacity for oxygen and nitrogen in the air, and combined with pressure swing method (circulation higher than atmospheric pressure adsorption and close to atmospheric pressure desorption).

Product Advantages:

· Compact design with skid mounted brings less limit for situation on site;

· Qualified gas can be produced within 15-30 minutes after start up;

· Automatic operation-one touch start up and shut down;

· High quality components and spare parts can serve for a long time.

Application fields:

PSA oxygen generators are widely used in different areas, including medical, plateau, environmental protection, combustion-supporting, cultivation, laboratory, chemical industry, electron, medicine, food, marine, aluminium soldering, lithium cell, heat treatment, laser cutting and etc.

Technical parameters:

● Oxygen delivery ≤66Nm3/hr;

● Purity 93%±3

● Pressure 0.4~1.0 Mpa

● Atmospheric dew point ≤－40℃

Product picture:
