PLC Program Controls PSA Oxygen Generator Used In Medical
PSA oxygen generator with high-quality components to ensure the more guaranteed of quality and longer service life
| Product name | PSA Oxygen Generator |
| Oxygen delivery | ≤66Nm3/hr |
| Purity | 93%±3 |
| Pressure | 0.4~1.0 Mpa |
| Atmospheric dew point | ≤－40℃ |
Working Principle Description:
PSA oxygen generator is based on the principle of pressure swing adsorption, using high-quality zeolite molecular sieve as adsorbent to produce oxygen from air under certain pressure. The dried compressed air is subjected to pressure adsorption and decompression desorption in the adsorber. Due to the aerodynamic effect, the diffusion rate of nitrogen in the micropores of zeolite molecular sieve is much higher than that of oxygen.
Nitrogen is preferentially adsorbed by zeolite molecular sieve, and oxygen is enriched in the gas phase to form finished oxygen. Then, after decompression and pressure, the adsorbent desorbs the adsorbed nitrogen and other impurities to realize regeneration. Generally, two adsorption towers are set in the system. One tower adsorbs oxygen and the other tower desorbs and regenerates. The PLC program controller controls the opening and closing of the pneumatic valve to make the two towers circulate alternately, so as to achieve the purpose of continuous production of high-quality oxygen.
Product Advantages:
- Using high-quality raw materials, the quality is guaranteed and the service life is longer.
- PSA oxygen generator has high-quality components so that the service life is longer and quality is more guaranteed.
- Because of the high-equality components, the PSA oxygen generator will have more guaranteed quality and longer service life.
- PSA oxygen is equipped with high-quality components, the guaranteed of quality and longer service life will be ensured.
Application fields:
PSA oxygen generators are widely used in different areas, including medical, plateau, environmental protection, combustion-supporting, cultivation, laboratory, chemical industry, electron, medicine, food, marine, aluminium soldering, laser cutting and etc.
Technical parameters:
● Oxygen delivery ≤66Nm3/hr;
● Purity 93%±3
● Pressure 0.4~1.0 Mpa
● Atmospheric dew point ≤－40℃
Product picture:
