Comprehensive and professional service will be offered for PSA nitrogen generator

Working Principle Description:

The air is compressed by the air compressor, and the air enters the buffer tank for storage. It is filtered by the filtration system to remove oil, dust and water. Then it is freeze-dried by the cold dryer and enters the nitrogen generation unit. The compressed air entering the nitrogen generation unit is first deeply removed of oil and water by the integrated high-efficiency filter, then stabilized by the air buffer tank and enters the adsorption tower filled with carbon molecular sieve. The clean compressed air is separated from oxygen and nitrogen here, and the prepared nitrogen is sent to the nitrogen buffer tank. After being detected by the nitrogen gas analyzer and measured by the flowmeter, the unqualified nitrogen is vented, and the qualified nitrogen is stored in the nitrogen storage tank for production.

Product Advantages:

• 7 * 24-hour comprehensive and professional service for PSA nitrogen generator can be offered if there is any problem.

• Molecular screening, filling and compaction are completed in a professional environment in a professional way, with higher density and efficiency.

• The design optimization of process and structure of PSA nitrogen generator enables the system to give full play to its potential.

• A million times of frequent switching of fault free special valves are adopted to ensure the stable operation of the system.

Application fields:

Nitrogen, commonly referred to as inert gas, is used in some inert atmospheres for metal treatment and in bulbs to prevent arcing, but it is not chemically inert. It is an essential element in animal and plant life and an integral part of many useful compounds. Nitrogen combines with many metals to form hard nitrides, which can be used as wear-resistant metals. A small amount of nitrogen in steel will inhibit grain growth at high temperature and improve the strength of some steels. It can also be used to produce a hard surface on steel. Nitrogen can be used to produce ammonia, nitric acid, nitrate, cyanide, etc; In the manufacture of explosives; Filled high temperature thermometer, incandescent bulb; Form inert material to preserve the material and use it in a drying oven or glove bag. Liquid nitrogen during food freezing; As a coolant in the laboratory.

Technical parameters:

● Nitrogen delivery ≤800Nm3/hr;

● Purity 99.999%

● Pressure 0.5~0.8 Mpa

● Atmospheric dew point ≤－40℃

Product picture:
