1100m3/h 1800m3/h 6m 10m 45kw 60hp Water Axial Flow Submersible Pump
Price:
Please contact us as below
MOQ:
1 set
Delivery Time:
7-15 working days
Brand:
APK
Product Description
QSZ submersible axial flow pump applications:
- Farmland irrigation, spray irrigation
- Water supply for industrial or residential buildings, water distribution in mountain areas
- Low-lying areas and dunes
- Water supply and drainage for mines in urban or rural districts
- Flood protection and drainage
QSZ submersible axial flow pump features:
- Axial/ Mixed Flow Submersible Pump various installation methods–horizontal, vertical, tilting.
- Pump and motor share the same shaft,improving rotor concentricity, less damage to shaft when pump working.
- The impeller angle is adjustable, highly improve the flow adjusted range.
- The motor is sealed three times, ensuring that there is no water leakage.
Axial flow water submersible pump models:
| Discharge Dia | Model | Flow range | Head range | Power |
| mm | QSZ type | m3/h | m | kw |
| 200 | QSZ300-6-10 | 300 | 6 | 10 |
| 250 | QSZ500-5-13 | 500 | 5 | 13 |
| 350 | QSZ800-3-13 | 800 | 3 | 13 |
| 400 | QSZ1000-3-18.5 | 1000 | 3 | 18.5 |
| 350 | QSZ1100-10-45 | 1100 | 10 | 45 |
| 500 | QSZ1500-4-22 | 1500 | 4 | 22 |
| 500 | QSZ1250-5-30 | 1250 | 5 | 30 |
| 550 | QSZ1600-4-30 | 600 | 4 | 30 |
| 550 | QSZ2100-3-30 | 2100 | 3 | 30 |
| 550 | QSZ1600-5-37 | 1600 | 5 | 37 |
| 550 | QSZ2000-4-37 | 2000 | 4 | 37 |
| 650 | QSZ2500-3-37 | 2500 | 3 | 37 |
| 550 | QSZ1900-5-45 | 1900 | 5 | 45 |
| 650 | QSZ2400-4-45 | 2400 | 4 | 45 |
| 750 | QSZ3000-3-45 | 3000 | 3 | 45 |
| 500 | QSZ1800-10-75 | 1800 | 10 | 75 |
QSZ submersible axial flow pump overview:
QSZ submersible axial flow pump working conditions:
-
Pump motor must be filled with clear water.
-
The temperature of the water being pumped shall not be more than 40°C.
-
PH value of the water being pumped shall be 5.5~8.5
