Electric Non Submersible Wastewater Pumps 11kw 15kw 37kw 50 Hp 100hp Power
WQ series submersible sewage pump can be customized with 304/316 stainless steel type, high temperature resistent type and cutting impeller type.
1. Type: WQ series sewage pump
2. Power: 11kw 15kw 37kw 50 Hp 100hp
3. Flow: 5-3500m3/h
4. Head: 5-200m
5. Material: Cast iron or stainless steel
WQ submersible sewage pump applications:
- Raw water, rain water
- Municipal and industrial waste water
- Sewage treatment
- Construction
WQ submersible sewage pump features:
- Motor:100% copper wire inside, full power.
- Mechanical seal: alloy and silicon carbide
- Shaft: 45# steel and stainless steel as your option
- Screw: stainless steel
11kw 15kw 37kw 50 hp 100hp sewage pump parameters:
| Outlet diameter |
Model |
Discharge flow | Lift head | Speed | Power | |
| mm |
WQ types |
m3/h | m | r/min | kw | hp |
| 100 |
100WQ80-24-11 |
80 | 24 | 2900 | 11 | 15 |
| 100 |
100WQ100-25-11 |
100 | 25 | 1450 | 11 | 15 |
| 100 |
100WQ80-32-15 |
80 | 32 | 2900 | 15 | 20 |
| 100 |
100WQ100-30-15 |
100 | 30 | 1450 | 15 | 20 |
| 150 |
150WQ130-15-11 |
130 | 15 | 1450 | 11 | 15 |
| 150 |
150WQ150-15-11 |
150 | 15 | 1450 | 11 | 15 |
| 150 |
150WQ100-30-15 |
100 | 30 | 1450 | 15 | 20 |
| 150 |
150WQ150-20-15 |
150 | 20 | 1450 | 15 | 20 |
| 150 |
150WQ150-45-37 |
150 | 45 | 1450 | 37 | 50 |
| 150 |
150WQ200-30-37 |
200 | 30 | 1450 | 37 | 50 |
| 200 |
200WQ300-7-11 |
300 | 7 | 1450 | 11 | 15 |
| 200 |
200WQ220-12-15 |
220 | 12 | 1450 | 15 | 20 |
| 200 |
200WQ300-25-37 |
300 | 25 | 980 | 37 | 50 |
| 200 |
200WQ350-25-37 |
350 | 25 | 1450 | 37 | 50 |
| 200 |
200WQ400-40-75 |
400 | 40 | 1450 | 75 | 100 |
| 250 |
250WQ500-16-37 |
500 | 16 | 980 | 37 | 50 |
| 250 |
250WQ600-12-37 |
600 | 12 | 1450 | 37 | 50 |
| 250 |
250WQ600-25-75 |
600 | 25 | 1450 | 75 | 100 |
| 250 |
250WQ600-28-75 |
600 | 28 | 1450 | 75 | 100 |
| 300 |
300WQ700-14-37 |
700 | 14 | 980 | 37 | 50 |
|
300 |
300WQ800-10-37 |
800 | 10 | 1450 | 37 | 50 |
| 300 |
300WQ800-20-75 |
800 | 20 | 1450 | 75 | 100 |
| 300 |
300WQ1000-20-75 |
1000 | 20 | 980 | 75 | 100 |
We can acccept ODM and OEM. Please send enquiry to us, if you need catalog and price.
Electric Non Submersible Sewage Pump Price:
We have many different models of cast iron electric sewage pump, the following chart is just for reference.
If you cannot find suitable model, just CONTACT US for suggestion, I will choose a suitable model for you.
We have cast iron, stainless steel 304 or 316.
We can customize 380V, 400V, 415V drainage pump as your request.
