Lake Rain Dirty Water Submersible Sewage Pump IP68 Resistant 11kw 15hp
11kw 15hp submersible sewage pump is maximum flow is 300m3/h, however, head is low. Main material is cast iron and stainless steel.
Our WQ sewage submersible pump is sewage pump developed on the basis of the introduction of foreign advanced technology. WQ series submersible sewage pump is power irrigation equipment united by the motor and the pump, especially the swirling impeller and double-channel impeller matched with spiral type centrifugal pump body, which have extremely strong drainage capacity.
The motor part adopts mechanical seals of hard corrosive double end face ceramic, which have very good effect of seepage prevention, its protection level is IP68 and designed insulation class is grade E, more rinning more safe, reliable, and long service life, convenient installation.
11kw 15hp submersible sewage pump overview:
- Flow: 35m3/h 100m3/h 130m3/h 150m3/h 300m3/h submersible sewage pump
- Head: 50m 25m 15m 13m 7m submersible sewage pump
- Power: 11kw 15hp submersible sewage pump
- Voltage: 380v/440v or as per request
- Frequency: 3 phase 50hz/60hz
- Material: Cast iron/stainless steel
WQ submersible sewage pump parameters:
| Model | Outlet diameter | Flow | Head | Power | Speed | |
|
WQ Series
|
mm | m3/h | m | kw | hp | r/min |
|
WQ50-18-30-3
|
50 | 18 | 30 | 3 | 4 | 2900 |
|
WQ50-40-15-4
|
50 | 40 | 15 | 4 | 5.5 | 2900 |
|
WQ50-25-32-5.5
|
50 | 25 | 32 | 5.5 | 7 | 2900 |
|
WQ50-20-40-7.5
|
50 | 20 | 40 | 7.5 | 10 | 2900 |
|
WQ65-25-15-2.2
|
65 | 25 | 15 | 2.2 | 3 | 2900 |
|
WQ65-25-30-4
|
65 | 25 | 30 | 4 | 5 | 2900 |
|
WQ65-30-40-7.5
|
65 | 30 | 40 | 7.5 | 10 | 2900 |
|
WQ65-35-50-11
|
65 | 35 | 50 | 11 | 15 | 2900 |
|
WQ80-43-13-3
|
80 | 43 | 13 | 3 | 4 | 2900 |
|
WQ80-40-15-4
|
80 | 40 | 15 | 4 | 5 | 2900 |
|
WQ80-65-25-7.5
|
80 | 65 | 25 | 7.5 | 10 | 2900 |
|
WQ100-110-10-5.5
|
100 | 110 | 10 | 5.5 | 7 | 1450 |
|
WQ100-100-15-7.5
|
100 | 100 | 15 | 7.5 | 10 | 1450 |
|
WQ100-80-20-7.5
|
100 | 80 | 20 | 7.5 | 10 | 1450 |
|
WQ100-100-25-11
|
100 | 100 | 25 | 11 | 15 | 1450 |
|
WQ125-130-15-11
|
125 | 130 | 15 | 11 | 15 | 1450 |
|
WQ150-150-13-11
|
150 | 150 | 13 | 11 | 15 | 1450 |
|
WQ200-300-7-11
|
200 | 300 | 7 | 11 | 15 | 1450 |
It is one part of 11kw 15hp submersible sewage pump parameters. If you would like to know more, please feel free to contact us.We will choose one suitable pump model for you.
