Construction Submersible Drainage Water Pumps Fecal Rain Sewage 37kw 50hp
Construction Fecal Rain Drainage Submersible Sewage Water Pump 37kw 50hp
Our WQ sewage submersible pump is sewage pump developed on the basis of the introduction of foreign advanced technology. WQ series submersible sewage pump is power irrigation equipment united by the motor and the pump, especially the swirling impeller and double-channel impeller matched with spiral type centrifugal pump body, which have extremely strong drainage capacity.
The motor part adopts mechanical seals of hard corrosive double end face ceramic, which have very good effect of seepage prevention, its protection level is IP68 and designed insulation class is grade E, more rinning more safe, reliable, and long service life, convenient installation.
37kw 50hp submersible sewage pump overview:
- Flow: 200m3/h 350m3/h 600m3/h submersible sewage pump
- Head: 30m 25m 12m submersible sewage pump
- Power: 37kw 50hp submersible sewage pump
- Voltage: 380v/440v or as per request
- Frequency: 3 phase 50hz/60hz
- Material: Cast iron/ss304/ss316/ss316l/duplex stainless
WQ submersible sewage pump parameters:
| Model | Outlet diameter (mm) | Flow (m3/h) | Head (m) | Power (kw) | Speed (r/min) |
| WQ50-18-30-3 | 50 | 18 | 30 | 3 | 2900 |
| WQ50-40-15-4 | 50 | 40 | 15 | 4 | 2900 |
| WQ50-25-32-5.5 | 50 | 25 | 32 | 5.5 | 2900 |
| WQ50-20-40-7.5 | 50 | 20 | 40 | 7.5 | 2900 |
| WQ65-25-15-2.2 | 65 | 25 | 15 | 2.2 | 2900 |
| WQ65-25-30-4 | 65 | 25 | 30 | 4 | 2900 |
| WQ65-30-40-7.5 | 65 | 30 | 40 | 7.5 | 2900 |
| WQ65-35-50-11 | 65 | 35 | 50 | 11 | 2900 |
| WQ65-35-60-15 | 65 | 35 | 60 | 15 | 2900 |
| WQ80-43-13-3 | 80 | 43 | 13 | 3 | 2900 |
| WQ80-40-15-4 | 80 | 40 | 15 | 4 | 2900 |
| WQ80-65-25-7.5 | 80 | 65 | 25 | 7.5 | 2900 |
| WQ100-110-10-5.5 | 100 | 110 | 10 | 5.5 | 1450 |
| WQ100-100-15-7.5 | 100 | 100 | 15 | 7.5 | 1450 |
| WQ100-80-20-7.5 | 100 | 80 | 20 | 7.5 | 1450 |
| WQ100-100-25-11 | 100 | 100 | 25 | 11 | 1450 |
| WQ100-100-30-15 | 100 | 100 | 30 | 15 | 1450 |
| WQ125-130-15-11 | 125 | 130 | 15 | 11 | 1450 |
| WQ125-130-20-15 | 125 | 130 | 20 | 15 | 1450 |
| WQ150-150-13-11 | 150 | 150 | 13 | 11 | 1450 |
| WQ150-180-15-15 | 150 | 180 | 15 | 15 | 1450 |
| WQ150-180-20-18.5 | 150 | 180 | 20 | 18.5 | 1450 |
| WQ150-180-25-22 | 150 | 180 | 25 | 22 | 1450 |
| WQ150-180-30-30 | 150 | 180 | 30 | 30 | 1450 |
| WQ150-130-30-22 | 150 | 130 | 30 | 22 | 1450 |
| WQ150-200-30-37 | 150 | 200 | 30 | 37 | 1450 |
| WQ200-300-7-11 | 200 | 300 | 7 | 11 | 1450 |
| WQ200-250-11-15 | 200 | 250 | 11 | 15 | 1450 |
| WQ200-250-15-18.5 | 200 | 250 | 15 | 18.5 | 1450 |
| WQ200-400-10-22 | 200 | 400 | 10 | 22 | 1450 |
| WQ200-400-13-30 | 200 | 400 | 13 | 30 | 1450 |
| WQ200-300-15-22 | 200 | 300 | 15 | 22 | 1450 |
| WQ200-250-22-30 | 200 | 250 | 22 | 30 | 1450 |
| WQ200-350-25-37 | 200 | 350 | 25 | 37 | 1450 |
| WQ250-500-7-22 | 250 | 500 | 7 | 22 | 1450 |
| WQ250-600-9-30 | 250 | 600 | 9 | 30 | 1450 |
| WQ250-600-9-37 | 250 | 600 | 9 | 37 | 1450 |
It is one part of 37kw 50hp submersible sewage pump parameters. If you would like to know more, please feel free to contact us.We will choose one suitable pump model for you.
