3 Phase 60hz / 50hz Deep Well Submersible Water Pump 14 - 388m Head Vertical Installation
3 Phase 60hz / 50hz Deep Well Submersible Water Pump 14 - 388m Head Vertical Installation
Submersible well water pump can be divided into two kinds, one is shallow well pump, the other is deep well submersible pump. Shallow well pump, as name suggests, used for shallow well. It is a kind of centrifugal pump with long transmission shaft, its structure is simple and high efficient. Compared with shallow one, deep well submersible pump is more broadly used.
Submersible well water pump is an important water supply device. It is used in residential water supply, agricultural irrigation, industrial cooling, sea water lift, geothermal heating and ship load.
It is consists of four main parts. They are water pump, submersible electric motor, water pipe and control switch.
Submersible well pump overview:
- Pump diameter: 8 10 12 Inch well submersible pump
- Flow rate: 18-540m3/h submersible pump
- Head rate: 14-388m
- Motor Power: 20hp 30hp 40hp 50hp 100hp submersible water pump
- Voltage:380v/420v/440v/660v /1140v or as per request
- Frequency: 3 phase 50hz/60hz
- Material: Cast iron/ss304/ss316/ss316L/Duplex stainless/SS904 (pump sets or casting parts)
- Install: Vertical
Submersible well pump applications:
- Groundwater pumping
- Irrigation system
- Water supply system
- Clean water supply
- Fountain project
- Water drawing system in hills and mountain areas
- Drawing water from wells
- Water supply and drainage system for industrial or civil buildings
- Water supply and drainage system system for mines and factories in cities or villages
- Sea water, salt water
20hp 30hp 40hp 50hp 100hp Submersible well pump parameters:
| Model | Power | Flow Range | Head Range | Outlet Size | |
| QJ Series | kw | hp | m3/h | m | Inch (") |
| 200QJ20-135/10 | 15 | 20 | 18-22 | 115-156 | 2" |
| 200QJ20-202/15 | 22 | 30 | 18-22 | 172-232 | 2" |
| 200QJ20-283/21 | 30 | 40 | 18-22 | 240-325 | 2" |
| 200QJ20-338/25 | 37 | 50 | 18-22 | 287-388 | 2" |
| 200QJ25-280/20 | 37 | 50 | 23-27 | 250-340 | 2" |
| 200QJ32-96/6 | 15 | 20 | 29-35 | 77-115 | 3" |
| 200QJ32-144/9 | 22 | 30 | 29-35 | 123-172 | 3" |
| 200QJ40-78/6 | 15 | 20 | 37-43 | 67-93 | 3" |
| 200QJ63-70/5 | 22 | 30 | 58-68 | 60-82 | 3" |
| 200QJ63-112/8 | 30 | 40 | 58-68 | 93-131 | 3" |
| 200QJ80-44/4 | 15 | 20 | 74-86 | 37-50 | 4" |
| 200QJ80-66/6 | 22 | 30 | 74-86 | 56-75 | 4" |
| 200QJ80-88/8 | 30 | 40 | 74-86 | 84-113 | 4" |
| 200QJ100-30/2 | 15 | 20 | 80-120 | 26-32 | 4" |
| 200QJ100-75/5 | 37 | 50 | 80-120 | 72-77 | 4" |
| 250QJ50-60/3 | 15 | 20 | 46-54 | 51-69 | 3" |
| 250QJ50-140/7 | 30 | 40 | 46-54 | 119-161 | 3" |
| 250QJ50-160/8 | 37 | 50 | 46-54 | 136-184 | 3" |
| 250QJ50-340/17 | 75 | 100 | 46-54 | 315-375 | 3" |
| 250QJ80-60/3 | 22 | 30 | 74-86 | 51-69 | 4" |
| 250QJ80-200/10 | 75 | 100 | 74-86 | 170-230 | 4" |
| 250QJ125-64/4 | 37 | 50 | 116-134 | 54-73 | 5" |
| 250QJ125-128/8 | 75 | 100 | 116-134 | 109-147 | 5" |
| 250QJ140-45/3 | 30 | 40 | 130-145 | 40-52 | 5" |
| 250QJ140-120/8 | 75 | 100 | 130-150 | 104-137 | 5" |
| 250QJ160-30/2 | 22 | 30 | 148-172 | 25-35 | 5" |
| 250QJ160-105/7 | 75 | 100 | 148-172 | 90-120 | 5" |
| 300QJ200-40/2 | 37 | 50 | 186-214 | 35-45 | 6" |
| 300QJ200-80/4 | 75 | 100 | 186-214 | 68-92 | 6" |
| 300QJ300-60/3 | 75 | 100 | 279-321 | 51-69 | 6" |
| 300QJ400-40/1 | 75 | 100 | 368-432 | 38-42 | 8" |
| 300QJ500-15/1 | 30 | 40 | 460-540 | 14-16 | 8' |
| 300QJ500-30/2 | 75 | 100 | 460-540 | 29-32 | 8' |
It is one part of 20hp 30hp 40hp 50hp 100hp submersible well pump parameters. If you would like to know more, please feel
free to send an inquiry.
