Dirty Water Electric Submersible Sewage Pump 30kw 50 Hp High Efficiency ISO9001

Price Negotiable

Price: Please feel free to contact us

MOQ: 1 piece

Delivery Time: 2-5 working days

Brand: APK

Product Description

30kw 40 hp electric sewage submersible pump performance range:

Flow: 150-1500m3/h
Head: 5-45m
Power: 30kw 40 hp
Outlet diameter: 150mm 200mm 250mm 300mm 350mm 400mm
Voltage: 380v/440v or as per request
Frequency: 3 phase 50hz/60hz
Material: cast iron/ss304/ss316/ss316l

No clogging sewage pump applications:

Water treatment equipment supporting
Enterprice wastewater discharge
Drainage system of city sewage treatment plant
Drainage station of subway
Underground chamber
Aair defense system
Sewage drainage of hospitals, hotels, high-rise buildings
Sewage drainage station of residental district

No clogging sewage pump features:

Single or dual channel impeller, ideal for discharging sewage.
The unique mechanical seal arrangement and bearing combination make the shaft stiff and extend the life of the mechanical seal.
The motor and the hydraulic components are directly connected into one body, which is convenient to disassemble, use and repair. The pump can be directly placed in the sewage pool, which can save capital investment.
There are a variety of installation methods that users have the flexibility to choose

30kw 50 hp electric sewage submersible pump parameters:

Outlet diameter	Types	Flow	Head	Speed	Power
mm	WQ Series	m3/h	m	r/min	kw
150	150WQ150-40-30	150	40	1470	30
150	150WQ160-45-30	160	45	1470	30
150	150WQ150-45-37	150	45	1470	37
150	150WQ200-30-37	200	30	1470	37
200	200WQ300-20-30	300	20	980	30
200	200WQ400-13-30	400	12	1470	30
200	200WQ300-25-37	300	25	980	37
200	200WQ350-25-37	350	25	1470	37
250	250WQ500-10-30	500	10	980	30
250	250WQ600-9-30	600	9	1470	30
250	250WQ500-16-37	500	16	980	37
250	250WQ600-12-37	600	12	1470	37
300	300WQ700-11-30	700	11	980	30
300	300WQ850-7-30	850	7	1470	30
300	300WQ700-14-37	700	14	980	37
300	300WQ800-10-37	800	10	1470	37
350	350WQ900-6-30	900	6	1470	30
350	350WQ1200-6-30	1200	6	730	30
350	350WQ1000-8-37	1000	8	1470	37
350	350WQ1200-8-37	1200	8	740	37
400	400WQ1500-5-30	1500	5	730	30
400	400WQ1500-6-37	1500	6	740	37

It is 30kw 50 hp electric sewage submersible pump parameters in the sheet. If you would like to know more details, please feel free to send an inquiry. We will reply as soon as possible.
