Electric Farm Irrigation Deep Well Submersible Pump Centrifugal 400m 37kw
centrifugal 400m 37kw electric farm irrigation lift pompa water deep well 8 inch submersible tube well water pump
Customer case:
20m3/h 81m 7.5kw 10hp 20 pieces water submersible pump to Indonesia
water submersible pump performance range:
* Flow: 13-120m3/h
* Lift: 12-465m
* Power: 7.5kw-55kw well submersible pump
* Voltage: 380v 440v 660v 1140v or as per request
* Frequency: 3 phase 50hz /60hz
Applications:
1. Ground water pumping
2. Irrigation system
3. Sea water, shipyard, offshore, floating dock, salt water
4. Drawing water from well
8 inch water submersible pump parameters:
600v/660v/1140v. If you would like to know more, please kindly contact us)
| Diameter | Model | Motor Power | Flow range | Head range | |
| Inch (") | QJ Series | kw | hp | m3/h | m |
| 8" | 200QJ15-81/6 | 7.5 | 10 | 13-17 | 68-92 |
| 8" | 200QJ20-189/14 | 22 | 30 | 18-22 | 160-217 |
| 8" | 200QJ20-230/17 | 25 | 35 | 18-22 | 195-265 |
| 8" | 200QJ20-338/25 | 37 | 50 | 18-22 | 287-388 |
| 8" | 200QJ20-351/26 | 45 | 60 | 18-22 | 298-403 |
| 8" | 200QJ25-154/11 | 18.5 | 25 | 23-27 | 138-184 |
| 8" | 200QJ25-168/12 | 22 | 30 | 23-27 | 140-195 |
| 8" | 200QJ25-308/22 | 37 | 50 | 23-27 | 260-355 |
| 8" | 200QJ32-176/11 | 30 | 40 | 29-35 | 148-203 |
| 8" | 200QJ32-182/14 | 30 | 40 | 29-35 | 154-210 |
| 8" | 200QJ32-234/18 | 37 | 50 | 29-35 | 199-270 |
| 8" | 200QJ32-273/21 | 45 | 60 | 29-35 | 232-313 |
| 8" | 200QJ40-104/8 | 18.5 | 25 | 37-43 | 89-124 |
| 8" | 200QJ40-117/9 | 22 | 30 | 37-43 | 94-140 |
| 8" | 200QJ40-130/10 | 25 | 35 | 37-43 | 114-155 |
| 8" | 200QJ40-169/13 | 30 | 40 | 37-43 | 144-201 |
| 8" | 200QJ40-182/14 | 37 | 50 | 37-43 | 154-214 |
| 8" | 200QJ40-195/15 | 37 | 50 | 37-43 | 166-232 |
| 8" | 200QJ40-234/18 | 45 | 60 | 37-43 | 206-277 |
| 8" | 200QJ50-45/3 | 10 | 14 | 46-54 | 36-54 |
| 8" | 200QJ50-52/4 | 13 | 18 | 46-54 | 42-62 |
| 8" | 200QJ50-104/8 | 25 | 35 | 46-54 | 84-124 |
| 8" | 200QJ50-135/9 | 30 | 40 | 46-54 | 119-162 |
| 8" | 200QJ50-143/11 | 37 | 50 | 46-54 | 121-165 |
| 8" | 200QJ50-169/13 | 37 | 50 | 46-54 | 143-195 |
| 8" | 200QJ50-195/13 | 45 | 60 | 46-54 | 165-225 |
| 8" | 200QJ50-195/15 | 45 | 60 | 46-54 | 165-225 |
| 8" | 200QJ63-28/2 | 7.5 | 10 | 58-68 | 24-33 |
| 8" | 200QJ63-84/6 | 25 | 35 | 58-68 | 72-96 |
| 8" | 200QJ63-98/7 | 30 | 40 | 58-68 | 84-114 |
| 8" | 200QJ63-112/8 | 30 | 40 | 58-68 | 93-131 |
| 8" | 200QJ63-126/9 | 37 | 50 | 58-68 | 100-147 |
| 8" | 200QJ63-140/10 | 45 | 60 | 58-68 | 120-164 |
| 8" | 200QJ63-154/11 | 45 | 60 | 58-68 | 130-180 |
| 8" | 200QJ80-33/3 | 13 | 18 | 74-86 | 28-37 |
| 8" | 200QJ80-44/4 | 15 | 20 | 74-86 | 37-50 |
| 8" | 200QJ100-15/1 | 7.5 | 10 | 80-120 | 12-16 |
| 8" | 200QJ100-45/3 | 22 | 30 | 80-120 | 42-47 |
| 8" | 200QJ100-60/4 | 30 | 40 | 80-120 | 58-62 |
| 8" | 200QJ100-105/7 | 45 | 60 | 80-120 | 102-107 |
50m3/h 195m 45kw 8 inch water submersible pump
32m3/h 144m 8 inch water submersible pump
APK pump factory not only manufacture water pumps, but also manufacture match pump accessories, including pump control cabinet, frequency converter(ABB or as per request), cable, valve.
Package: the well pump has 3 layers of packaging with 8mm special export wooden box. Shock absorption, moisture-proof package.
FAQ:
1. What's your MOQ?
one piece
2. What's your deliver method?
Sea freight, express, airplane
3. What's your payment?
T/T
