25hp 15kw 50m3/h 78m 8 Inch Farm Irrigation Deep Borewell Submersible Pump
8inch 10 15 75 25 hp 15kw submersible pumps farm agricultural irrigation bore well water submersible pump
Applications:
1. Ground water pumping
2. Irrigation system
3. Sea water, shipyard, offshore, floating dock, salt water
4. Drawing water from well
8 inch submersible water pump parameters:
| Diameter | Model | Motor Power | Flow range | Head range | |
| Inch (") | QJ Series | kw | hp | m3/h | m |
| 8" | 200QJ15-81/6 | 7.5 | 10 | 13-17 | 68-92 |
| 8" | 200QJ20-189/14 | 22 | 30 | 18-22 | 160-217 |
| 8" | 200QJ20-230/17 | 25 | 35 | 18-22 | 195-265 |
| 8" | 200QJ20-338/25 | 37 | 50 | 18-22 | 287-388 |
| 8" | 200QJ20-351/26 | 45 | 60 | 18-22 | 298-403 |
| 8" | 200QJ25-154/11 | 18.5 | 25 | 23-27 | 138-184 |
| 8" | 200QJ25-168/12 | 22 | 30 | 23-27 | 140-195 |
| 8" | 200QJ25-308/22 | 37 | 50 | 23-27 | 260-355 |
| 8" | 200QJ32-176/11 | 30 | 40 | 29-35 | 148-203 |
| 8" | 200QJ32-182/14 | 30 | 40 | 29-35 | 154-210 |
| 8" | 200QJ32-234/18 | 37 | 50 | 29-35 | 199-270 |
| 8" | 200QJ32-273/21 | 45 | 60 | 29-35 | 232-313 |
| 8" | 200QJ40-104/8 | 18.5 | 25 | 37-43 | 89-124 |
| 8" | 200QJ40-117/9 | 22 | 30 | 37-43 | 94-140 |
| 8" | 200QJ40-130/10 | 25 | 35 | 37-43 | 114-155 |
| 8" | 200QJ40-169/13 | 30 | 40 | 37-43 | 144-201 |
| 8" | 200QJ40-182/14 | 37 | 50 | 37-43 | 154-214 |
| 8" | 200QJ40-195/15 | 37 | 50 | 37-43 | 166-232 |
| 8" | 200QJ40-234/18 | 45 | 60 | 37-43 | 206-277 |
| 8" | 200QJ50-45/3 | 10 | 14 | 46-54 | 36-54 |
| 8" | 200QJ50-52/4 | 13 | 18 | 46-54 | 42-62 |
| 8" | 200QJ50-104/8 | 25 | 35 | 46-54 | 84-124 |
| 8" | 200QJ50-135/9 | 30 | 40 | 46-54 | 119-162 |
| 8" | 200QJ50-143/11 | 37 | 50 | 46-54 | 121-165 |
| 8" | 200QJ50-169/13 | 37 | 50 | 46-54 | 143-195 |
| 8" | 200QJ50-195/13 | 45 | 60 | 46-54 | 165-225 |
| 8" | 200QJ50-195/15 | 45 | 60 | 46-54 | 165-225 |
| 8" | 200QJ63-28/2 | 7.5 | 10 | 58-68 | 24-33 |
| 8" | 200QJ63-84/6 | 25 | 35 | 58-68 | 72-96 |
| 8" | 200QJ63-98/7 | 30 | 40 | 58-68 | 84-114 |
| 8" | 200QJ63-112/8 | 30 | 40 | 58-68 | 93-131 |
| 8" | 200QJ63-126/9 | 37 | 50 | 58-68 | 100-147 |
| 8" | 200QJ63-140/10 | 45 | 60 | 58-68 | 120-164 |
| 8" | 200QJ63-154/11 | 45 | 60 | 58-68 | 130-180 |
| 8" | 200QJ80-33/3 | 13 | 18 | 74-86 | 28-37 |
| 8" | 200QJ80-44/4 | 15 | 20 | 74-86 | 37-50 |
| 8" | 200QJ100-15/1 | 7.5 | 10 | 80-120 | 12-16 |
| 8" | 200QJ100-45/3 | 22 | 30 | 80-120 | 42-47 |
| 8" | 200QJ100-60/4 | 30 | 40 | 80-120 | 58-62 |
| 8" | 200QJ100-105/7 | 45 | 60 | 80-120 | 102-107 |
FAQ:
1. What is your MOQ?
Normally our MOQ is 1.
2. Can you offer sample?
Yes, we can provide samples for testing
3. What is your delivery time?
We wil deliver in 15-20 work days
8 inch deep well submersible pump performance range:
1. Diameter: 8 inch submersible pump
2. Flow: 13m3/h-120m3/h
3. Head: 12m-465m
4. Power: 2.2kw-55kw; 3hp-75hp
5. Voltage: 380v/440v/460v/480v/600v/660v/1140v
6. Material : Cast iron/stainless steel 304/316/316l/duplex stainless/super duplex stainless steel/904l
20m3/h 54m 5.5kw submersible water pump
20m3/h 81m 7.5kw 10hp water submersible pump
40m3/h 52m 10kw submersible water pump
Payment & Delivery
Payment: 100% deposit by T/T before production, or large quantity 30% deposit by T/T, and balance paid before shipment.
Package: 3 layers of packaging with 8mm special export wooden box, Shock absorption,moisture-proof package
Shipment: 1. By sea: 15~30 days, DHL, Fedex, UPS, TNT. suitable for regular Mass Production.
2. By express: 3~7 days, suitable for Urgent Time and Small Quantity.
3. By airport: 4~5 days, from airport to airport.
