7.5KW 0.8mm Slotted Shutter Guide Making Machine hydraulic cutting
Siemens PLC System Full Automatic Shutter Door Roll Forming Machine High Speed
1. Description of shutter door roll forming machine:
The machine is used for doors, bases, and roller shutter doors.
Rolling shutters, rolling shutters, rolling shutters, or partial overhead doors are a type of door or shutter, consisting of a number of horizontal slats (or sometimes a strip or web system) hinged together. Raise the door to open it, then lower it to close it.
The rolling door machine includes a 3-ton manual uncoiler, a forming machine with post-cutting, a hydraulic station, a PLC controller, and a workbench
Mitsubishi or Siemens control system, shutter door forming machine works automatically.
And Lebron Machinery Factory also manufactured a slotted shutter door forming machine
2. Technical details of shutter door roll forming machine:
| Machine Specifications | |
| Weight | About 4000kgs |
| Size | About 7m x 1.8m x 1.5m (length x width x height) |
| Color | Main color: light blue |
| Warning color: yellow | |
| Suitable Raw Material | |
| Material | Galvanized Steel Coils |
| Thickness | 0.3-0.8mm |
| Main Technical Parameters | |
| Quantity of forming rollers stations | 20 |
| The diameter of forming rollers shafts | 75mm |
| Roll Forming Speed | 15-18m/min |
| Forming rollers material | No.45 steel, coated with a chromed treatment |
| Cutter material | Cr12 mold steel, with quenched treatment |
| Controlling system | PLC and Converter |
| Electric Power requirement | Main motor power: 7.5kw |
| Hydraulic unit motor power: 4kw | |
| Electric voltage | According to customer’s requirement |
3. Main components of shutter door roll forming machine
| Decoiler | 1 Set |
| Feeding Device | 1 Set |
| Roll Forming Unit | 1 Set |
| Post Cutting Unit | 1 Set |
| Hydraulic Station | 1 Set |
| Electric Control Cabinet | 1 Set |
| Receiving Table | 1 Set |
