3000 Series 3003 Aluminum Round Tube Good Formability For Liquid Or Gaseous Media
Hollow Aluminum Tube 3000 Series 3003 with Good Formability 15mm Aluminum Round Tube Used in Liquid or Gaseous Media
3000: 3003 and 3A21 are representative of this series . It is a series with good anti-rust function.Y&G is Aluminum Tube, Aluminum Pipe, Aluminium Tube manufacturer / supplier in China, offering 3003 O Anodized Aluminum Tube/Pipe (GYB02), Powder Coated Aluminium Extruded Profile for Kitchen, Competitive Aluminum Tube and so on.
Production Description:
| Item Name | 3000 Series 3003 15mm Aluminum Round Tube |
| Material Grade | 3A21,3003,3103,3004,3005,3105 and other series |
| Surface treatment | Mill finish, anodizing, powder coated, sandblasting, electrophoresis etc |
| Color | Silvery white, black, golden, champagne, dark bronze or according to your requirement |
| Shape | Square, Round, Flat, or according to customers' drawings |
| Length | The Standard length of export is 5.8m , Anodizing 6.5 meters at most, Mill finish 13 meters at most |
| Deep processing | cutting, drilling, punching, bending etc |
| Quality Control | 1.SO Approved. 2.CE Approved 3.Inspection at Site. 4.Inspection Before Shipping. 5.Testing Machine. |
| Packing details | 1.EP Paper inside for each profile separate then craft paper outside 2.EP Paper inside for each profile separate then carton paper then pallet 3. Shrink film 4.wooden carton |
| Delivery | 15-25days after receiving down payment |
Chemical Composition:
| Grade | Si | Fe | Cu | Mn | Mg | Cr | Ni | Zn | Ti | Zr | Al |
| 3003 | 0.6 | 0.7 | 0.05-0.2 | 1.0-1.5 | — | — | — | 0.10 | — | — | Balance |
Mechanical Properties:
| Grade | Temper | Wall Thickness(mm) | Tensile Strength(Mpa) | Yield strength(Mpa) | Elongation(%) |
| 3003 | O | All | 95-130 | — | ≥25 |
| H112 | All | ≥95 | — | ≥25 |
Applications: 3003 aluminum round tubes are mainly used for low load parts requiring high plasticity and good weldability, working in liquid or gaseous media, such as petrol or lubricating oil conduits, various liquid containers and other small load parts made with deep drawing , wire used to do rivets.
Mark: As required.
