China Anti Wear Carbon Steel Line Pipe API 5L Grade B For Petroleum Transportation for sale

Anti Wear Carbon Steel Line Pipe API 5L Grade B For Petroleum Transportation

Price Negotiable

Price: Negotiable

MOQ: Negotiation

Delivery Time: 25-35 days

Brand: Y & G

Product Description

Steel Line Pipe Seamless Carbon Steel Line Pipes API 5L Grade B For Petroleum Transportation

Pipeline is the extraction of oil, gas and water from the ground through the pipeline to the oil and gas industry. Pipeline consists of seamless pipe and welded steel pipe with flat ends, threaded ends and socket ends. Way for the welding, coupling connections, socket connections.

Standard: API SPEC 5L, ISO 3183,GB/T 9711.1-199

Grades: A53,A25,A,B,X42,X46,X52,X56,X60,X65,X70,X80...

Product Specification Level: PSL-1,PSL-2

Size Range: 10.29 mm to 609mm.

NPS IN	OD MM	Sch10	Sch20	Sch30	STD	Sch40	Sch60	Sch80	XS	Sch100	Sch120	Sch140
1/8	10.29	-	-	-	1.73	1.73	-	2.41	2.41	-	-	-
1/4	13.72	-	-	-	1.73	1.73	-	3.02	3.02	-	-	-
3/8	17.14	-	-	-	2.31	2.31	-	3.2	3.2	-	-	-
1/2	21.34	-	-	-	2.77	2.77	-	3.73	3.73	-	-	-
3/4	26.67	-	-	-	2.87	2.87	-	3.91	3.91	-	-	-
1	33.4	-	-	-	3.38	3.38	-	4.55	4.55	-	-	-
1 1/4	42.16	-	-	-	3.56	3.56	-	4.85	4.85	-	-	-
1 1/2	48.26	-	-	-	3.68	3.68	-	5.08	5.08	-	-	-
2	60.32	-	-	-	3.91	3.91	-	5.54	5.54	-	-	-
2 1/2	73.02	-	-	-	5.16	5.16	-	7.01	7.01	-	-	-
3	88.9	-	-	-	5.49	5.49	-	7.62	7.62	-	-	-
3 1/2	101.6	-	-	-	5.74	5.74	-	8.08	8.08	-	-	-
4	114.3	-	-	-	6.02	6.02	-	8.56	8.56	-	11.12	-
5	141.3	-	-	-	6.55	6.55	-	9.53	9.53	-	12.7	-
6	168.3	-	-	-	7.11	7.11	-	10.97	10.97	-	14.27	-
8	219.1	-	6.35	7.04	8.18	8.18	10.31	12.7	12.7	15.09	18.26	20.62
10	273.1	-	6.35	7.8	9.27	9.27	12.7	12.7	12.7	18.26	21.44	25.4
12	323.9	-	6.35	8.38	9.52	10.3	14.27	12.7	12.7	21.44	25.4	28.58
14	355.6	6.35	7.92	9.52	9.52	11.13	15.09	12.7	12.7	23.83	27.79	31.75
16	406.4	6.35	7.92	9.52	9.52	12.7	16.66	12.7	12.7	26.19	30.96	36.52
18	457.2	6.35	7.92	11.12	9.52	14.27	19.05	12.7	12.7	29.36	34.92	39.47
20	508	6.35	7.92	12.7	9.52	15.09	20.62	12.7	12.7	32.54	38.1	44.45
22	558.8	6.35	7.92	12.7	9.52	-	22.22	12.7	12.7	34.92	41.28	47.62
24	609.6	6.35	7.92	14.27	9.52	17.48	24.61	12.7	12.7	38.89	46.02	52.37

Application: This is steel pipe for pipeline transportation systems in the petroleum and natural gas industries. API 5L is suitable for conveying gas, water, and oil.
