Heat Resistant Plastic Conjugate Ring Packing High Free Volume For Petroleum Industry
Heat Resistant Plastic Conjugate Ring Packing High Free Volume For Petroleum Industry
Plastic Conjugate Ring packing is made from heat resistant and chemical corrosion resistant plastics. It has features such as high free volume, low pressure drop, low mass-transfer unit height, high flooding point, uniform gas-liquid contact, small specific gravity, high mass transfer efficiency and so on, and the application temperature in media ranges from 60 Degree C to 150 Degree C. For these reasons it is widely used in the packing towers in petroleum industry, chemical industry, alkali-Chloride industry, coal gas industry and environmental protection, etc.
Material:Polypropylene(PP), Reinforced Polypropylene(RPP), Reinforced Nylon 6, Reinforced Nylon 66…
Specification of Plastic Conjucate Rings
|
Diameter (mm) |
Size (mm) |
Surface Area (m2/m3) |
Void Rate (m3/m3) |
Number Per M3 |
| 25 | 25x25x1.2 | 185 | 0.90 | 74000 |
| 38 | 38x38x1.5 | 142 | 0.91 | 16000 |
| 50 | 50x50x1.5 | 104 | 0.92 | 9500 |
| 76 | 76x76x3.6 | 81 | 0.93 | 3900 |
Feature: It draw benefits of ring and saddle packing .Owing to conjugate curve rib structure and appropriate length,there are point contact and aren't intussusceptive between packings and tower or packings It has better hydrodynamics and mass transfer performance.
Application: Distillation, Gas absorption, Deabsorption system.
