Corrosion Resistant Nickel Alloy Tube Nickel Capillary Tube For Oil And Gas Extraction
nickel capillary tube
Product Introduction
| Item Name | nickel capillary tube |
| Grade | Ni200, Ni201, N4, N6 |
| Standard | ASTM B161 B163 |
| Dimension(MM) | OD10-168 xID0.5-10x 100-18000 MM |
1. Metal Chemical Composition:
| Grade | Ni+Co | Cu | Si | Mn | C | Mg | S | P | Fe |
| N4 | 99.9 | 0.015 | 0.03 | 0.002 | 0.01 | 0.01 | 0.001 | 0.001 | 0.04 |
| N6 | 99.5 | 0.10 | 0.10 | 0.05 | 0.10 | 0.10 | 0.005 | 0.002 | 0.10 |
| Ni201 | 99.0 | ≤0.25 | ≤0.35 | ≤0.35 | ≤0.02 | ≤0.01 | ≤0.40 | ||
| Ni200 | 99.0 | 0.20 | 0.30 | 0.30 | 0.15 | 0.01 | 0.40 |
2. Metal Mechanical Properties:
| Diameter |
Tensile strength, min Mpa, pound/in2 |
Yield strength(0.2%offset) ,min Pound/in2 |
Elongation in 4D or 4W min,% | |||
| UNS N02200 | UNS N02201 | UNS N02200 | UNS N02201 | UNS N02200 | UNS N02201 | |
| Outer diameter<=5in(127mm |
55000 (380) |
50 000 (345) |
15 000 (105) |
12 000 (80) |
35 | 35 |
|
Outer diameter <5in(127mm) |
55 000 (380) |
50 000 (345) |
12 000 (80) |
10 000 (70) |
40 | 40 |
3. Applications:
Heat exchanger coil pipe
Chemical processing
Marine Engineering
Power Generation
Oil and Gas Extraction
Petrochemical processing
Telecommunications
4. Features:
1. Excellent corrosion resistant to turbulently used in condensers for coastal power plants,
petroleum refineries and chemical plants.
2. High impingement corrosion resistant to brackish seawater at velocities up to 3 to 4 m/sec
used in desalination plants and other seawater condenser application.
