Corrosion Resistance mechanical 5083 Aluminum Alloy Bar
Aluminum Alloy 5083
Aluminum 5083-H321, UNS A95083, ISO AlMg4.5Mn, Aluminium 5083-H116, Aluminium 5083-H321, AA5083-H116
Aluminum 5083 is an extremely versatile heat treatable aluminum alloy due to its content of silicon and magnesium. 6061 has a wide range of mechanical and corrosion resistance properties as well as having most of the good qualities of aluminum. 6061 is used in a many applications from aircraft structures, yacht construction, truck bodies, bicycle frames to screw machine parts.
Aluminum 5083 chemical composition:
| Grades | Si | Fe | Cu | Mn | Cr | Mg | Ti | Zn | Others Total |
| 5083 | 0.40 max | 0.40 max | 0.10 max | 0.40 / 1.0 | 0.05 / 0.25 | 4.0 / 4.90 | 0.15 max | 0.25 max | 0.15 max |
Typical Mechanical Properties:
| Material | Temper | Tensile Strength (ksi) min | Yield Strength (ksi) min | Elongation % in 2" |
| 5083 Extruded Bar (<5" diameter) |
0 | 39 | 16 | 14 |
| 5083 Extruded Bar (<5" diameter) |
H111 | 40 | 24 | 12 |
| 5083 Extruded Bar (<5" diameter) |
H112 | 39 | 16 | 12 |
Application
This material is used for pressure vessels, tip truck bodies, rail cars, ship building, vehicle bodies and mine skips & cages
