China Stainless Steel Pipe AISI ASTM A249 SS 201 304 304L 316 316L 317L Welded Seamless Inox Stainless Steel Tube for Boiler for sale

Stainless Steel Pipe AISI ASTM A249 SS 201 304 304L 316 316L 317L Welded Seamless Inox Stainless Steel Tube for Boiler

Name: Stainless Steel Pipe AISI ASTM A249 SS 201 304 304L 316 316L 317L Welded Seamless Inox Stainless Steel Tube for Boiler
Brand: Y & G International Trading Company Limited

Price Negotiable

Price: Negotiable

MOQ: Negotiation

Delivery Time: 25-35 days

Brand: Y & G

Product Description

Stainless Steel Pipe AISI ASTM A249 SS 201 304 304L 316 316L 317L Welded Seamless Inox Stainless Steel Tube for Boiler

Material	Stainless Steel 304/304L/316L
Shape	Round / Square / Rectangle
Production Standards	ASTM A270, ASTM A269, ASTM A249, ASTM A778, ASTM A789, DIN 11850, EN 10357, EN 10217-7 and so on.
Production Standards
Size	Outer diameter = 16 - 2000mm ; Thickness = 0.8 - 20 mm ; Length = 6 - 18.3 meter ; Or as customer' s request.
Tolerance	According to the Standard , +/-10% Commonly ;
Surface Treatment	180#, 320#, 400# Satin / Hairline, Bright Anneal, Pickle,400#, 500#, 600# or 800# Mirror finish
Process Characteristics	Inner Welded Seam Removed ; Online Bright Solution Anneal ; Inner Electro Polish And Mechanical Polish ;
Application	Petrochemical Industry ; Chemical Fertilizer Industry ; Oil Refining Industry ; Oil And Gas Industry ; Light Industry And Food Industry ; Pulp And Paper Industry ; Energy And Environmental Industries .
Test	Flaring test ; Flattening test ; Bending Test ; Hydraulic Test ; Eddy Current test
Design	OEM / ODM / Customized
Certificate	ISO9001 ; ISO14001; ISO 18001; TUV ; SGS

Stainless Steel Mechanical Properties
Grade		Tensile Strength	Yide Strength	Elogation	Hardness	Solution Annealing
Grade		kgf/mm²(N/mm²)	kgf/mm²(N/mm²)	%	HRB(HV)	ºC
ASTM	TP 304	≥53 (515)	≥21 (205)	≥35	≤90 (200)	1040ºC-1150ºC Water Quenching
	TP 304L	≥50 (485)	≥17 (170)
	TP 316	≥53 (515)	≥21 (205)
	TP 316L	≥50 (485)	≥17 (170)
JIS	SUS 304	≥53 (520)	≥21 (205)			1010ºC-1150ºC Water Quenching
	SUS 304L	≥49 (480)	≥18 (175)
	SUS 316	≥53 (520)	≥21 (205)
	SUS 316L	≥49 (480)	≥18 (175)
GB	06Cr19Ni10	≥53 (520)	≥21 (210)			1010ºC-1150ºC Water Quenching
	022Cr19Ni10	≥49 (480)	≥18 (180)
	06Cr17Ni12Mo2	≥53 (520)	≥21 (210)
	022Cr17Ni12Mo2	≥59 (480)	≥18 (180)
EN	1.4301	(500-700)	≥20 (195)	≥40		1000ºC-1100ºC Water Quenching
	1.4307	(470-670)	≥18 (180)			1000ºC-1100ºC Water Quenching
	1.4401	(510-710)	≥21 (205)			1020ºC-1120ºC Water Quenching
	1.4404	(490-690)	≥19 (195)			1020ºC-1120ºC Water Quenching

Stainless Steel Heat Exchanger Tube
Standard	OD(mm)	WT(mm)	Length(meters)	Grade
ASTM A249, ASTM A269, EN 10217-7	15.88 to 114.3	0.3 to 4.0	Up to 18.3 meter	1.4301, 1.4306, 1.4404, AISI 304/304l/316l, S31803/S32205, etc
Standard	Outside Diameter		Thickness	Length
ASTM A249 (A1016)	<25.4	±0.10	±10%S	OD<50.8+3-0 OD≥50.8+5-0
	≥25.4~<38.1	±0.15
	≥38.1~<50.8	±0.20
	≥50.8~<63.5	±0.25
	≥63.5~<76.2	±0.31
ASTM A269 (A1016)	<38.1	±0.13	OD<12.7±15% OD≥12.7±10%	OD<38.1+3.2-0 OD≥38.1+4.8-0
	≥38.1~<88.9	±0.25
	≥88.9~<139.7	±0.38

Chemical Composition	Tensile Strength	Yield Strength	Elongation	Hardness HRB
Grade 304 Stainless Steel (100% & MPA)
C≤0.08, Mn≤2, P≤0.045, S≤0.03, Si≤0.75, 8≤Ni≤10.5, 18≤Cr≤20	≥515	≥205	≥40	≤92
Grade 304L Stainless Steel (100% & MPA)
C≤0.03, Mn≤2, P≤0.045, S≤0.03, Si≤0.75, 8≤Ni≤12, 18≤Cr≤20	≥485	≥170	≥40	≤92
Grade 316L Stainless Steel (100% & MPA)
C≤0.03, Mn≤2, P≤0.045, S≤0.03, Si≤0.75, 10≤Ni≤14, 16≤Cr≤18	≥485	≥170	≥40	≤95
