China 90 Degree 45 Degree A234 / A420 Wpi B16.9 Carbon Steel Pipe Elbow for sale

90 Degree 45 Degree A234 / A420 Wpi B16.9 Carbon Steel Pipe Elbow

Price Negotiable

Price: Negotiable

MOQ: Negotiation

Delivery Time: 25-35 days

Brand: Y & G

Product Description

Carbon Steel Pipe Fitting 90 Degree Elbow 45 Degree Elbow A234/A420 Wpi B16.9

Bend is a commonly used connection pipe for plumbing installation. It is used to connect the pipe and change the direction of the pipe.

Product Name	Elbow
Standard	ASME/ANSI B16.5/16.36/16.47A/16.47B, MSS S44, ISO70051, JISB2220, BS1560-3.1, API7S-15, API7S-43, API605, EN1092
Materials	Stainless steel:ASTM/ASMES/A182F304 \| F304L \|F304H \| F316 \| F316L \| F321 \| F321H \| F347\|316Ti \| 309S \|310S \| 405 \|409\|410 \| 410S \| 416 \| 420 \| 430 \| 630 \| 660 \| 254SMO \| 253MA \| 353MA Nickel Alloy: ASTM/ASME S/B366 UNS N08020\| N04400\|N06600\| N06625\| N08800\| N08810\|N08825\| N10276\|N10665\|N10675\|Incoloy 800 \| Incoloy 800H \| Incoloy 800HT \| Incoloy 825 \| Incoloy 901 \| Incoloy 925 \| Incoloy 926, Inconel 600 \| Inconel 601 \| Inconel 625 \| Inconel 706 \| Inconel 718 \| Inconel X-750, Monel 400 \| Monel 401 \| Monel R 405 \| Monel K 500 Super Stainless Steel: ASTM/ASME S/A182 F44, F904L, F317LS32750 \| S32760 Hastelloy:HastelloyB \| HastelloyB-2 \| HastelloyB-3 \| HastelloyC-4 \| Hastelloy C-22 \| Hastelloy C-276 \| Hastelloy X \|Hastelloy G \| Hastelloy G3 Nimonic: Nimonic 75 \| Nimonic 80A \| Nimonic 90 Duplex Steel: ASTM A182 F51 \| F53 \| F55, S32101 \| S32205\|S31803 \| S32304 Alloy Steel: ASTM/ASME S/ A182 F11 \| F12 \| F22 \| F5 \| F9 \| F91 Ti alloy:ASTM R50250/GR.1 \| R50400/GR.2 \| R50550/GR.3 \| R50700/GR.4 \| GR.6 \|R52400/GR.7 \| R53400/GR.12 \| R56320/GR.9 \|R56400/GR.5 Carbon steel: A234 WPB \| A420 WPL6
Marking	Supply Logo + Standard + Size(mm) + HEAT NO +or as your requirement
Test	Chemical Component Analysis, Mechanical Properties, Metallurgical Analysis, Impact Testing, Hardness testing , Ferrite Testing, Intergranular corrosion testing, X-ray Inspection (RT), PMI, PT, UT, HIC & SSC test, etc. or as your requirment
Certificates	ISO, BV, CE, PED, KOC, CCRC, PDO, CH2M HILL and etc.
Applications	Ø EN 1.4835 has a good weldability and can be welded using the following methods: 1. Shielded metal arc welding (SMAW) 2. Gas tungsten arc welding, GTAW (TIG) 3. Plasma arc welding (PAW) 4. Gas metal arc GMAW (MIG) 5. Submerged-arc welding (SAW) Ø Typical application areas for 1.4835: 1. Ovens 2. Construction 3. Building 4. As details at high temperature
Advantages	ü Corrosion Resistance ü Heat Resistance ü Heat Treatment ü Welding ü Machining

Drawing:

Nominal Pipe Size		Center to End			Center to Center		Back to Back
Nominal Pipe Size		45°Elbow	90°Elbow		180°Return
DN	NPS	H	F		P		K
DN	NPS	LR	LR	SR	LR	SR	LR	SR
15	1/2	16	38	/	76	/	48	/
20	3/4	19	38	/	76	/	51	/
25	1	22	38	25	76	51	56	41
32	11/4	25	48	32	95	64	70	52
40	11/2	29	57	38	114	76	83	62
50	2	35	76	51	152	102	106	81
65	21/2	44	95	64	190	127	132	100
80	3	51	114	76	229	152	159	121
90	31/2	57	133	89	267	178	184	140
100	4	64	152	102	305	203	210	159
125	5	79	190	127	381	254	262	197
150	6	95	229	152	457	305	313	237
200	8	127	305	203	610	406	414	313
250	10	159	381	254	762	508	518	391
300	12	190	457	305	914	610	619	497
350	14	222	533	356	1067	711	711	533
400	16	254	610	406	1219	813	813	610
450	18	286	686	457	1372	914	914	686
500	20	318	762	508	1524	1016	1016	762
550	22	343	838	559	1676	1118	1118	838
600	24	381	914	610	1829	1219	1219	914
650	26	405	991	660
700	28	438	1067	711
750	30	470	1143	762
800	32	502	1219	813
850	34	533	1295	864
900	36	565	1372	914
950	38	600	1448	965
1000	40	632	1524	1016
1050	42	660	1600	1067
1100	44	695	1676	1118
1150	46	727	1753	1168
1200	48	759	1829	1219

Application: Due to its good comprehensive performance, the bend is widely used in basic projects such as chemicals, construction, water supply, drainage, oil, heavy and heavy industries, refrigeration, sanitation, water heating, fire protection, electricity, aerospace, and shipbuilding.
