316 Stainless Steel Valve Bushing Gleitlager For Butterfly Valve Bushing
The 316 Stainless Steel Valve Bushing Gleitlager designed for butterfly valve bushings is a high-performance component that offers exceptional durability and corrosion resistance. Constructed from 316 stainless steel, this bushing is known for its ability to withstand harsh environments and demanding applications.
The Gleitlager design, which translates to "sliding bearing" in German, refers to the self-lubricating properties of the bushing. This feature ensures smooth and efficient operation of the butterfly valve, even under high loads and temperatures. The self-lubricating material creates a lubricating film that reduces friction and wear, significantly extending the lifespan of the valve and reducing maintenance requirements.
The 316 stainless steel material used in the construction of this bushing provides superior corrosion resistance, making it suitable for use in a wide range of environments, including those with high humidity, chemicals, and saltwater. This corrosion resistance also helps maintain the dimensional stability of the bushing, ensuring it fits perfectly into the valve and maintains its original shape and size.
The precision engineering of this 316 Stainless Steel Valve Bushing Gleitlager ensures it meets the strict requirements of butterfly valve applications. It is designed to fit perfectly into the valve, providing a smooth and reliable seal that prevents leakage and ensures the valve operates as intended.
Overall, the 316 Stainless Steel Valve Bushing Gleitlager for butterfly valve bushings is a reliable and cost-effective solution that offers superior durability, corrosion resistance, and self-lubricating properties. It is an excellent choice for butterfly valve applications that require high performance and reduced maintenance.
Stainless Steel Bushings
Butterfly Valve Plain Bearings Accessories,Stainless Steel Bushings - Pipe Fittings Bearings Provides Our Global Valves And Pipelines And Other Chemical Industries With Unique Design Solutions To Complex Problems And An Unparalleled Level Of Service, Quality, And Support.Mechanical Joining
Self-Lubricating Bearings Technology Form The Basis For Our Mechanical Joining. All Sleeve Bushings Are Manufactured To Exacting Standards And For Optimal Performance To Satisfy Your Piping Requirements.
Butterfly Valves Bushes Ball Valves Globe Valves Gate Valves Stainless Steel 316 /Tex Valve Bushings Gleitlager
Stainless Steel 316 Bearings + Fabric Viiplus Sliding Bearing Solutions For Your Valve Applications
Application
BALL VALVES(flange ball valves)
LINED BALL VALVES BUSHINGS
RISING STEM BALL VALVES BUSHINGS
SEGMENTED BALL VALVES
TOP ENTRY BALL VALVES BUSHINGS
TRUNNION MOUNTED BALL VALVES BUSHINGS
TECHNISCHE DATEN
- Wrapped composite sliding bearing
- Carbon-steel / fibres fabric
- Maintentance-free
- Available on request
PROPERTIES
- Excellent sliding and wear behaviour, especially in case of rotating and oscillating movement, good shock absorption, very high load capacity, no water absorption
MATERIALS
- Support materialCarbon steel
- Sliding layer fibres fabric
- Support material: Stainless steel and bronze on request
MATERIAL PROPERTIES
- Specific load capacity static≤ 350 [N/mm2]
- Specific load capacity dynamic≤ 180 [N/mm2]
- Sliding speed< 0.5 [m/s] 1 [m/s] lubricated
- Friction value ***0.03 [µ] to 0.20 [µ]
- Temperature strain– 50 [°C] to + 250 [°C]
- Max. PV-value1.8 [N/mm² x m/s]
MOUNTING ADVISE
- The application of an adequate force fitting mandrel is advisable
TOLERANCE DETAILS
- Housing ØH7
- Bushing inner-Ø after mountingH9
- Shaft tolerancef7 to h8
|
|
|||||
|
Max.Load |
Static |
350N/mm2 |
|
Temp. |
-50°C~+250°C |
|
Dynamic |
180N/mm2 |
||||
|
Friction coefficient |
0.03~0.20 |
||||
|
Max.speed |
Dry |
0.5m/s |
|||
|
Thermal conductivity |
42W(m x K) 1 |
||||
|
Grease |
1m/s~3m/s |
||||
|
Max.PV(Dry) |
Short-term |
3.6N/mm2 m/s |
Coefficient of thermal |
11 x 10- 6 x K-1 |
|
|
Continuous |
1.8N/mm2 m/s
|
||||
MAINTENANCE
- is a dry sliding bearing with glued fibres fabric overlay. Lubrication is therefore not necessary and not allowed.
RANGE OF APPLICATION
- Machine and crane construction, apparatus engineering, agricultural machines, fittings, water pumps, chemical industry
CAPTION
This sliding bearing type and special dimensions are only available on request
Application
Now this product has been used like suspension and auxiliary of agriculture and construction machines,cranes and hydraulic and mechanical jibs,ball butterfly and sluice valves,water pumps,chemical industries etc.
