Professional Fluid Solenoid Valve Bushings , Slef Lubricating Steel Bushing
When it comes to fluid solenoid valves, the role of bushings cannot be underestimated. Professional fluid solenoid valve bushings, specifically designed as self-lubricating steel bushings, offer several key advantages that ensure smooth and reliable valve operation.
Self-lubricating steel bushings are made from a special alloy that has inherent lubricating properties. This means that they do not require additional lubricants to function effectively, significantly reducing maintenance requirements and downtime. The self-lubricating material also helps to reduce friction and wear, extending the lifespan of the bushing and the valve itself.
In addition to their self-lubricating properties, professional fluid solenoid valve bushings are precision-engineered to fit the specific requirements of the valve. They are designed to provide a tight and reliable seal between the valve stem and the valve body, preventing fluid leakage and ensuring consistent performance.
The steel material used in these bushings offers excellent strength and durability, ensuring that they can withstand the rigors of continuous operation in demanding industrial environments. The bushings are also resistant to corrosion and other forms of degradation, further extending their service life.
In summary, professional fluid solenoid valve bushings made from self-lubricating steel offer a reliable and long-lasting solution for ensuring smooth and efficient valve operation. Their unique combination of materials and precision engineering ensures superior performance and durability in even the most challenging applications.
Professional Fluid Solenoid Valve Bushings
Fluid Solenoid Solution The bearing used stainless steel and a self-lubricating separator of fiberglass reinforced TEX. To give additional strength to the riveted separator in this bearing,Woven Fabric Liner were added More wear resistance and corrosion resistance extend life Wrapped composite sliding bearing Stainless steel 316 / fibres fabric gleitlager valve bushings application | VSB-36
Professional fluid solenoid valve bushings manufacturers
solenoid valves bushings & pumps bushings
Favorable China Price + Stable Quality=Competitiveness
Stainless steel backing sintered with bronze powder overlaid with fibres fabric Suitable for dry running, low coefficient of friction, lower wear.
APPLICATION
VIIPLUS 2018
Make The FutureTog
Browse our viiplus catalogue
VIIPLUS SLIDING BEARING SOLUTIONS FOR YOUR APPLICATIONS
TECHNISCHE DATEN
- Wrapped composite sliding bearing
- Carbon-steel / fibres fabric
- Maintentance-free
- Available on request
|
|||||
| Max.Load | Static | 350N/mm2 | Temp. | -50°C~+250°C | |
| Dynamic | 180N/mm2 | ||||
| Friction coefficient | 0.03~0.20 | ||||
| Max.speed | Dry | 0.5m/s | |||
| Thermal conductivity | 42W(m x K) 1 | ||||
| Grease | 1m/s~3m/s | ||||
| Max.PV(Dry) | Short-term | 3.6N/mm2 m/s | Coefficient of thermal expansion |
11 x 10- 6 x K-1 | |
| Continuous |
1.8N/mm2 m/s |
||||
PROPERTIES
- Excellent sliding and wear behaviour, especially in case of rotating and oscillating movement, good shock absorption, very high load capacity, no water absorption
MATERIALS
- Support materialCarbon steel
- Sliding layer fibres fabric
- Support material: Stainless steel and bronze on request
MATERIAL PROPERTIES
- Specific load capacity static≤ 350 [N/mm2]
- Specific load capacity dynamic≤ 180 [N/mm2]
- Sliding speed< 0.5 [m/s] 1 [m/s] lubricated
- Friction value ***0.03 [µ] to 0.20 [µ]
- Temperature strain– 50 [°C] to + 250 [°C]
- Max. PV-value1.8 [N/mm² x m/s]
MOUNTING ADVISE
- The application of an adequate force fitting mandrel is advisable
TOLERANCE DETAILS
- Housing ØH7
- Bushing inner-Ø after mountingH9
- Shaft tolerancef7 to h8
MAINTENANCE
it is a dry sliding bearing with glued fibres fabric overlay. Lubrication is therefore not necessary and not allowed.
RANGE OF APPLICATION
- Machine and crane construction, apparatus engineering, agricultural machines, fittings, water pumps, chemical industry
CAPTION
This sliding bearing type and special dimensions are only available on request
