25 28 30 35 Metric Flanged Bearing Bush Tin Or Copper Plating
The 25, 28, 30, and 35 metric flanged bearing bush, available with either tin or copper plating, is a precision-engineered component designed to provide robust and reliable performance in various industrial applications.
The flanged design of the bearing bush offers additional support and stability, ensuring a secure fit and preventing any potential slippage or misalignment. The metric sizes of 25, 28, 30, and 35 allow for easy integration into a wide range of equipment and machinery, making it a versatile and convenient choice for industrial use.
The bearing bush is constructed from high-quality materials, ensuring durability and long-term performance. The optional tin or copper plating further enhances its performance, improving corrosion resistance and providing additional lubricity. This plating also enhances the bush's appearance, giving it a professional and polished finish.
Wh used in machinery, automotive components, or any other industrial application, the 25, 28, 30, 35 metric flanged bearing bush with tin or copper plating is an excellent choice for providing smooth and efficient operation. Its precision manufacturing and robust design ensure reliable performance even under high loads and extreme conditions.
In summary, the 25, 28, 30, 35 metric flanged bearing bush with tin or copper plating is a high-quality, precision-engineered component that offers robust performance and long-term durability for industrial applications. Its versatile metric sizes and optional plating make it a convenient and effective solution for a wide range of bearing needs.
25 28 30 35 - Metric Flanged Bearing Bush
Lined Wrapped Bearings - The Ideal Choice For Industrial Engineers & Specialists. Our Metric flange Bearings Series Features Metric & Imperial Plain, Flanged, Washers & Strip Options. Plain Bearings. Flanged Bearings. Washers, ptfe bearing!
Get A Quote
Contact Our Friendly Team Today
On Hand To Answer Any Questions
Bush Bearings
Lined Wrapped Bearings
Developed Many Applications
25 28 30 35 - Metric Flanged Bearing Bushing, Bearings | Self Lubricating Bearings ,Plain Bearings Supplier, bearings
Plain Bushing Supplier - Leading Bushing Specialists
Lined Steel Bearings - The Ideal Choice For Industrial Engineers & Specialists.
bmf Flanged Bearing Bush,Bearing Supplier | Bearing Manufacturer
Details, spinodal bronze with optional lubrication holes/indentations
Low Friction Bushing bearings
Inner Diameter |
25 |
|---|---|
Outer Diameter |
28 |
Length |
30 |
Flange Thickness |
1.5 |
Flange Diameter |
35 |
Surface Style |
Smooth |
Dry slide bearing has a common structure, consisting of a steel backing
Bushing Type: Sleeve; Dimensions
Slide bushing bearing metric diameter and/or length. Modified pU Factor. Bushes. Flanged Bushes. Thrust Washers.
Bushing Bushing Slitted type Bearings supply Metal + Sintered Bronze POM sheets. With Steel Backing, Bushings thrust washers and strips - Bearings, 50 bushings, Same-Day ShipmentsPap Bushing Bushing Slitted type, carbon steel Bushes supplier.
Metal-polymer bearings BUSH WITH BRONZE BACKING for dry and lubricated applications in corrosive environments. Cylindrical & flanged bushes, thrust washers.
| Max PV – Dry (N/mm² x m/s) | 0.6 |
|---|---|
| Max PV – Oiled (N/mm² x m/s) | 9.6 |
| Max Static load (N/mm²) | 820 |
| Max Dynamic load (N/mm²) | 340 |
| Max Sliding speed – Dry (m/s) | 3 |
| Max Sliding speed – With Oil (m/s) | 10 |
| Operating temperature (°C) | -250 to 300 |
| Thermal Conductivity (W/mk) | 38 |
| Coefficient of thermal expansion | 16.4 x 10-6/°C |
| Coefficient of friction – Dry | 0.25 |
| Coefficient of friction – With Oil | 0.04 |
| Recommended shaft finish (Ra) | 0.4 max (N5) |
| Recommended shaft hardness (HRC) | 60 |
| Hardness (HRC) | 30 min |
| Ultimate Tensile strength (N/mm²) | 860 |
| Yield strength (N/mm²) | 725 |
| Elongation (%) | 10 |
| Elastic modulus (N/mm²) | 144000 |
Tolerances & Fittings (Metric)
| Min | Max | Tolerance | |
|---|---|---|---|
| Overall Length | 29.750 | 30.250 | |
| Flange Diameter Tolerance | 34.500 | 35.500 | |
| Recommended Housing Size | 28.000 | 28.021 | H7 |
| Shaft Diameter | 25.000 | 25.052 | h7 |
| Inside Diameter When Fitted | 25.000 | 25.052 | H9 |
