L7805CV voltage regulator TO-220 L7805 7805 5V POSITIVE VOLTAGE REGULATORS

Features

• Output current to 1.5 A
• Output voltage of 5V
• Thermal overload protection
• Short circuit protection
• Output transition SOA protection

Description

The L7805CV of three-terminal positive regulators is available in TO-220 package, making it useful in awide range of applications.

These regulators can provide lacal on-card regulation, eliminating the distribu-tion problems associated with single point regulation.

Each type employs internal current limiting, thermal shut-down and safe area protection, making it essentially indestructible.

If adequate heat sinking is provided,they can deliver over 1.5 A output current.

Although designed primarily as fixed voltage regulators, these devices can be used with external components to obtain adjustable voltage and currents.
