284-907 Protective Spring Clamp PA66 Terminal Block Tin Plated Brass Body Front Entry DIN Rail Green Color
284-907 Din Mount Spring Terminal Blocks
284-907 Protective Spring Clamp Terminal Block Tin Plated Brass Body Front Entry
1. DESCRIPTION
The spring cage terminal blocks are designed to avoid the vibration. The Ground terminal blocks can be installed on the DIN Rail tightly without any tool.Green and yellow shell. The internationally accepted color designation for ground circuits.
Steady structure.
Fast and safe installation.
Long durable time.
Simple and convenient operation.
Shock resistance & Corrosion resistance.
Suitable for various applications.
Reduce the installation time and speed the wiring.
Made from Inflaming Nylon PA 66, Tin plated brass.
Connecting capacity from 1.5 to 10 mm.
Maintenance free vibration proof connection.
Front entry design-save time.
Universal mounting feet.
2.TECHNICAL PARAMETERS
| Model Number | 284-907 |
| Color | Yellow/Green, other color can be customized |
| Length/Height/Wide (mm) | 77/42/10 |
| Connection method | Spring-cage connection |
| Material | Nylon PA66 |
| Rated Voltage/Current | 800V/57A |
| Cross section | 0.2-10mm² |
| Conductor Size | 24-8 AWG |
| Mounting Type | NS 35/7.5 |
| Standard | IEC 60947-7-1 |
| LOGO | WonkeDQ, Customized LOGO is accept |
| Packing Detail | 32.25g/pc, 25PCS/BOX, 700PCS/CTN |
| Certification | CE/RoHS/CQC/ISO 9001 |
-
