160LM/W High Bay LED Lights , MOSO Customized Drivers Type 60W LED High Bay Light
160LM/W Higher Transmittance Lens 60Watt LED High Bay Fitting With MOSO Customized Drivers
60Watt LED High Bay Fitting=9000 lumens, up to 150 lumens to watt, 200 watt HID/HPS Equivalent.
Good lighting can prevent costly mistakes, correct visibility problems and lead to increased efficiency
Features
1. Luminous efficacy up to 150 lm/W
2. Simple to replace your old high bay light or make a new installation.
Perfect for warehouse lighting, garage lighting, supermarket lighting, factory lighting and shop lighting
3. Meanwell HBG series driver and Nichia 3030 LED make the LED high bay light fixtures durable without quality headache. With an expected lifespan of 50,000 hours, the LED light will reduce costs for maintenance
4. Up to 17'(5m) mounting height
5. Customized Drivers,Normally we used MOSO drivers except Meanwell drivers
| Produce Code |
HBL-60Watt HBL-80W 100W HBL-120W150W HBL-200W240W |
||||||
| Power | 60Watt | 80W 100W | 120W 150W | 200W 240W | |||
| Input Voltage | 90-305VAC | ||||||
| Input Current |
60W:0.27A@220VAC 80W: 0.36A@220VAC 100W:0.45A@220VAC 120W:0.55A@220VAC 150W:0.68A@220VAC 200W:0.91A@220VAC 240W:1.10A@220VAC |
||||||
| PF | >0.90@220VAC | ||||||
| DC output voltage | 60W:54V 80W100W120W150W: 48V | ||||||
| DC output current | 60W:1.05A 80W: 1.5A 100W: 1.9A 120W: 2.3A 150W:2.9A 200W:3.9A 240W:4.65A | ||||||
| Dimming (Optinal) | 3 in 1 dimming (PWM, 0-10V, Resistor),Dali | ||||||
| CCT | 4000K,5000K,5700K,3000K | ||||||
|
Ra >70 5000K |
Typical Flux |
60W:9000Lm±5%,80W:12000Lm±5%,100W:15000Lm±5%, 120W:18000Lm±5%,150W:22500Lm±5%,200W:30000Lm±5% 240W:36000Lm±5% |
|||||
| LED Brand | Nichia 3030 and Lumileds 3030 | ||||||
| Beam Angle | 60°,90°,120° | ||||||
| Operation Temp | -40℃ ~ +45℃ | ||||||
| Storage Temp | -40℃ ~ +85℃ | ||||||
| Life Circle | 45℃ 50000Hours | ||||||
| IP Class | IP66 | ||||||
| IK Class | IK08 | ||||||
| Certificate | CE,ROHS | ||||||
| Body Color | Black (default with RAL9005),Gray ( optional for RAL9007) | ||||||
60Watt LED High Bay UFO Lights Delivery
Components of Sunluxx Warehouse LED High Bay Fixtures
Applications
