LED High Bay Warehouse Lighting Fixture Anti - Aging Electrostatic Spray - Paint Processed
Surface Anti-aging Electrostatic Spray-paint Processing LED High Bay Lamp Warehouse Lighting
Features
1. Perfect for warehouse lighting, garage lighting, supermarket lighting, factory lighting and shop lighting
2. Meanwell HBG series driver and Lumileds 3030 LED make the LED high bay light fixtures durable without quality headache.
3. Up to 33’(10m) mounting height
| Produce Code | HBL-60Watt HBL-80W 100W HBL-120W150W HBL-200W240W | ||||||
| Power | 60Watt | 80W 100W | 120W 150W | 200W 240W | |||
| Input Voltage | 90-305VAC | ||||||
| Input Current | 60W:0.27A@220VAC 80W: 0.36A@220VAC 100W:0.45A@220VAC | ||||||
| PF | >0.90@220VAC | ||||||
| DC output voltage | 60W:54V 80W100W120W150W: 48V | ||||||
| DC output current | 60W:1.05A 80W: 1.5A 100W: 1.9A 120W: 2.3A 150W:2.9A 200W:3.9A 240W:4.65A | ||||||
| Dimming (Optinal) | 3 in 1 dimming (PWM, 0-10V, Resistor),Dali | ||||||
| CCT | 4000K,5000K,5700K,3000K | ||||||
Ra >70 | Typical Flux | 60W:9000Lm±5%,80W:12000Lm±5%,100W:15000Lm±5%, | |||||
| LED Brand | Nichia 3030 and Lumileds 3030 | ||||||
| Beam Angle | 60°,90°,120° | ||||||
| Operation Temp | -40℃ ~ +45℃ | ||||||
| Storage Temp | -40℃ ~ +85℃ | ||||||
| Life Circle | 45℃ 50000Hours | ||||||
| IP Class | IP66 | ||||||
| IK Class | IK08 | ||||||
| Certificate | CE,ROHS | ||||||
| Body Color | Black (default with RAL9005),Gray ( optional for RAL9007) | ||||||
120Watt LED UFO Retrofit Kits High Bay Light Distribution
