EU 240W LED Stadium Flood Light 33600LM 200 - 305V AC For Outdoor High Pole Lighting
EU 240W LED Basketball Stadium flood light 33600lm Outdoor High Pole Lighting, 200 - 305VAC
Features
1. 5 years warranty.
2. NICHIA SMD LED chip + MEANWELL driver, high lumen of 140lm/W.
3. 200-305VAC, 347V, Europe standard wide voltage range.
4. Beam angle: ANB, AWB, SNB, SWB
5. Die cast Aluminum housing provide better heat dissipation solution, long life, low failure, no glare.
6. IP66 waterproof for outdoor lighting, IK10 impact resistance, strong and stable.
7. Adjustable bracket, easy installation, satisfy different applications.
8. Electrostatic protective powder coating for lasting lamp appearance.
9. Strong wind resistance, high vibration resistance.
Product Details
| Power | 240W | |
| Input Voltage | 90 - 305VAC | |
| Input Current | 1.10A@220VAC | |
| PF | >0.9@220VAC | |
| DC Output Voltage | 48V | |
| DC Output Current | 4.65A | |
| Dimming (Optional) | 3 in one dimming(PMW, 1-10V,Resistor), DALI | |
| CCT | 4000k, 5000k, 5700K, 3000K and 2700K can be customized | |
| Ra>80,5000K | Typical Flux | 31200lm±10% |
| Efficiency | 130lm/W±10% | |
| Ra>70,5000K | Typical Flux | 33600lm±10% |
| Efficiency | 140lm/W±10% | |
| LED Brand | NICHIA 3030 | |
| Light Type | Asymmetric and symmetric polarized light | |
| Operation Temp. | -40 ℃ to + 45 ℃ | |
| Storage Temp. | -40 ℃ to + 85 ℃ | |
| Lifespan | 45℃ , 50,000 hours | |
| IP Class | 66 | |
| IK Class | 10 | |
| Lamp Body Color | Grey or as customized | |
| Product Size(mm) | 441*373*50 | |
| Net Weight(kg) | 6.37 | |
| Packing size(mm) | 540*460*190 | |
| Gross Weight(kg) | 13.5 | |
| Product Quantity Per Carton | 2pcs | |
| Installation Method | Bracket Mount | |
Beam Angle
Accessories
Light Distribusion Curve
Installation Manual
Applications
Garden Lighting,Park Lighting,Billboard Lighting,Landscape Lighting,Building Lighting,Stadium Lighting
