Compact 120W High Bay LED Lights Orange Lampshade Type For Bread Processing Factory
Orange Lampshade 120W NSF LED Food High Bay For Bread Processing Factory
Features of LED Food High Bay
1. Compact and Fashion design
2. Luminous efficacy 170 lm/W, 90°Beam Angle, high power factor
3. Uniform light distribution
4. The first patented proprietary optics and higher transmittance 95% water wave lens
5. Surface anti-aging electrostatic spray-paint processing, ensure longer lifespan
6. 60/90/120 degree IES distribution selection, national listing lab tested with IES standard.
| Item | CHBL-100 | CHBL-120 | CHBL-150 |
| Power | 100W | 120W | 150W |
| Input Voltage | 90-305VAC | 90-305VAC | 90-305VAC |
| Input Current | 0.47A@220VAC | 0.57A@220VAC | 0.68A@220VAC |
| PF | >0.90@220VAC | >0.90@220VAC | >0.90@220VAC |
|
Dimming Option MOSO |
2 in 1 dimming (PWM, 0-10V) | 2 in 1 dimming (PWM, 0-10V) | 2 in 1 dimming (PWM, 0-10V) |
|
Dimming Option Meanwell |
3 in 1 dimming (PWM, 1-10V, Resistor) / Dali | 3 in 1 dimming (PWM, 1-10V, Resistor) / Dali | 3 in 1 dimming (PWM, 1-10V, Resistor) / Dali |
|
Ra>80 Luminous Flux |
14000Lm | 16800Lm | 21000Lm |
|
Ra>70 Luminous Flux |
16000Lm | 19200Lm | 24000Lm |
| LED Brand | Cree SMD 3030 / LUMILEDS 3030 | Cree SMD 3030 / LUMILEDS 3030 | Cree SMD 3030 / LUMILEDS 3030 |
| Beam Angle | 60°90°120° | 60°90°120° | 60°90°120° |
| Operation Temp | -40℃ ~ +45℃ | -40℃ ~ +45℃ | -40℃ ~ +45℃ |
| Storage Temp | -40℃ ~ +85℃ | -40℃ ~ +85℃ | -40℃ ~ +85℃ |
| Lifespan | 25℃ 50000Hours | 25℃ 50000Hours | 25℃ 50000Hours |
| IP rating | IP69K | IP69K | IP69K |
| IK rating | IK10 | IK10 | IK10 |
| Certificates | ETL, CE,SAA,ROHS,NSF | ETL, CE,SAA,ROHS,NSF | ETL,CE,SAA,ROHS,NSF |
| Lamp Body Color | Orange( RAL2004) | Orange( RAL2004) | Orange( RAL2004) |
| Product Size(mm) | 400*400*197 | 400*400*197 | 400*400*197 |
| Net Weight(kg) | 5.6kg | 5.6kg | 5.6kg |
| Packing Size(mm) | 480*480*220 | 480*480*220 | 480*480*220 |
| Gross Weight(kg) | 6.8kg | 6.8kg | 6.8kg |
| Installation Way | Hook Mount/Pendant Mount | Hook Mount/Pendant Mount | Hook Mount/Pendant Mount |
FAQ for LED Food High Bay
Q1. Can I have a sample order for LED Food High Bay?
A1: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A:Sample needs 3-5 days, mass production time needs 1-2 weeks
Q3. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q4: Do you offer guarantee for the products?
A: Yes, we offer 5 years warranty to our products.
Applications
